79
ENG
pRack PR300T +0300018EN rel. 1.5 - 02.05.2017
Mask index Description Channel Logic Notes
Other functions
Baace Heat recovery, line 2
Baadg, Egba01 ChillBooster fault, line 2
Baade Enable oating condenser, line 2
Baacm, Cbd06, Dbd08 Setpoint compensation, line 2
Baacn pRack automatic or manual operation status
Dba52 Anti noise, line 2
Dba53 Split condenser, line 2
Eeba02 Heat recovery activation, line 2
Eaba15 Maximum receiver oil level, line 2
Eaba16 Minimum receiver oil level, line 2
Eaba17 Oil level compressor 1 line 2
Eaba18 Oil level compressor 2 line 2
Eaba19 Oil level compressor 3 line 2
Eaba20 Oil level compressor 4 line 2
Eaba21 Oil level compressor 5 line 2
Eaba22 Oil level compressor 6 line 2
Generic F.
Baacf, Efe16 DI generic input F
Baacg, Efe17 DI generic input G
Baach, Efe18 DI generic input H
Baaci, Efe19 DI generic input I
Baacj, Efe20 DI generic input J
Digital outputs
Line 1
Mask index Description Channel Logic Notes
Suction
Bac02, Caa08
Line relay compressor 1 line 1
Partwinding/ Star relay compressor 1 line 1
Delta relay compressor 1 line 1
Bac03, Caa09 Valve 1, compressor 1 line 1
Bac04, Caa10 Valve 2, compressor 1 line 1
Bac05, Caa11 Valve 3, compressor 1 line 1
Bac07, Caa12 Equalization valve compressor 1 line 1
Bac08, Caa22
Line relay compressor 2 line 1
Partwinding/ Star relay compressor 2 line 1
Delta relay compressor 2 line 1
Bac10, Caa23 Valve 1, compressor 2 line 1
Bac11, Caa24 Valve 2, compressor 1 line 1
Bac12, Caa25 Valve 3, compressor 1 line 1
Bac13, Caa26 Equalization valve compressor 1 line 1
Bac15, Caa35
Line relay compressor 3 line 1
Partwinding/ Star relay compressor 3 line 1
Delta relay compressor 3 line 1
Bac16, Caa36 Valve 1, compressor 3 line 1
Bac17, Caa37 Valve 2, compressor 3 line 1
Bac18, Caa38 Valve 3, compressor 3 line 1
Bac20, Caa39 Equalization valve compressor 3 line 1
Bac21, Caa47
Line relay compressor 4 line 1
Partwinding/ Star relay compressor 4 line 1
Delta relay compressor 4 line 1
Bac22, Caa48 Valve 1, compressor 4 line 1
Bac23, Caa49 Valve 2, compressor 4 line 1
Bac24, Caa50 Valve 3, compressor 4 line 1
Bac26, Caa51 Equalization valve compressor 4 line 1
Bac28, Caa60
Line relay compressor 5 line 1
Partwinding/ Star relay compressor 5 line 1
Delta relay compressor 5 line 1
Bac29, Caa61 Valve 1, compressor 5 line 1
Bac30, Caa62 Valve 2, compressor 5 line 1
Bac31, Caa63 Valve 3, compressor 5 line 1
Bac33, Caa64 Equalization valve compressor 5 line 1
Bac34, Caa72
Line relay compressor 6 line 1
Partwinding/ Star relay compressor 6 line 1
Delta relay compressor 6 line 1
Bac35, Caa73 Valve 1, compressor 6 line 1
Bac36, Caa74 Valve 2, compressor 6 line 1
Bac37, Caa75 Valve 3, compressor 6 line 1
Bac39, Caa76 Equalization valve compressor 6 line 1
Bac41, Caa80
Line relay compressor 7 line 1
Partwinding/ Star relay compressor 7 line 1
Delta relay compressor 7 line 1
Bac42, Caa81 Valve 1, compressor 7 line 1
Bac43, Caa82 Valve 2, compressor 7 line 1
Bac45, Caa83 Equalization valve compressor 7 line 1
Bac46, Caa86
Line relay compressor 8 line 1
Partwinding/ Star relay compressor 8 line 1
Delta relay compressor 8 line 1
Bac47, Caa87 Valve 1, compressor 8 line 1
Bac48, Caa88 Valve 2, compressor 8 line 1
Bac50, Caa89 Equalization valve compressor 8 line 1
Bac51, Caa92
Line relay compressor 9 line 1
Partwinding/ Star relay compressor 9 line 1
Delta relay compressor 9 line 1
Bac52, Caa93 Valve 1, compressor 9 line 1
Bac55, Caa94 Equalization valve compressor 9 line 1
Bac56, Caa96
Line relay compressor 10 line 1
Partwinding/ Star relay compressor 10 line 1
Delta relay compressor 10 line 1
Bac57, Caa97 Valve 1, compressor 10 line 1
Bac60, Caa98 Equalization valve compressor 10 line 1
Bac61, Caaaa
Line relay compressor 11 line 1
Partwinding/ Star relay compressor 11 line 1
Delta relay compressor 11 line 1
Bac62, Caaab Valve 1, compressor 11 line 1
Bac65, Caaac Equalization valve compressor 11 line 1
Page 135 of 177
Copyright HPL January 2021
P4115S Rev 02
