pRack PR300T +0300018EN rel. 1.5 - 02.05.2017
Mask index Description Channel Logic Notes
Other functions
Eaaa56 Minimum receiver oil level, line 1
Eaaa57 Oil level compressor 1 line 1
Eaaa58 Oil level compressor 2 line 1
Eaaa59 Oil level compressor 3 line 1
Eaaa60 Oil level compressor 4 line 1
Eaaa61 Oil level compressor 5 line 1
Eaaa62 Oil level compressor 6 line 1
Line 2
Mask index Description Channel Logic Notes
Suction
Ac08, Baacy ON/OFF unit, line 2
Baaap, Cbaah Common low pressure switch, line 2
Baadb, Cba14 Compressor inverter warning, line 2
Baaar, Cbaaj Common oil alarm, line 2
Baa61, Cba01 Alarm 1 compressor 1, line 2
Baa62, Cba02 Alarm 2, compressor 1 line 2
Baa63, Cba03 Alarm 3, compressor 1 line 2
Baa64, Cba04 Alarm 4, compressor 1 line 2
Baa65, Cba05 Alarm 5, compressor 1 line 2
Baa66, Cba06 Alarm 6, compressor 1 line 2
Baa67, Cba07 Alarm 7, compressor 1 line 2
Baa68, Cba15 Alarm 1 compressor 2, line 2
Baa69, Cba16 Alarm 2, compressor 2 line 2
Baa70, Cba17 Alarm 3, compressor 2 line 2
Baa71, Cba18 Alarm 4, compressor 2 line 2
Baa72, Cba19 Alarm 5, compressor 2 line 2
Baa73, Cba20 Alarm 6, compressor 2 line 2
Baa74, Cba21 Alarm 7, compressor 2 line 2
Baa76, Cba28 Alarm 1, compressor 3 line 2
Baa77, Cba29 Alarm 2, compressor 3 line 2
Baa78, Cba30 Alarm 3, compressor 3 line 2
Baa79, Cba31 Alarm 4, compressor 3 line 2
Baa80, Cba32 Alarm 5, compressor 3 line 2
Baa81, Cba33 Alarm 6, compressor 3 line 2
Baa82, Cba34 Alarm 7, compressor 3 line 2
Baa83, Cba40 Alarm 1, compressor 4 line 2
Baa84, Cba41 Alarm 2, compressor 4 line 2
Baa85, Cba42 Alarm 3, compressor 4 line 2
Baa86, Cba43 Alarm 4, compressor 4 line 2
Baa87, Cba44 Alarm 5, compressor 4 line 2
Baa88, Cba45 Alarm 6, compressor 4 line 2
Baa89, Cba46 Alarm 7, compressor 4 line 2
Baa91, Cba53 Alarm 1, compressor 3 line 2
Baa92, Cba54 Alarm 2, compressor 3 line 2
Baa93, Cba55 Alarm 3, compressor 3 line 2
Baa94, Cba56 Alarm 4, compressor 3 line 2
Baa95, Cba57 Alarm 5, compressor 3 line 2
Baa96, Cba58 Alarm 6, compressor 3 line 2
Baa97, Cba59 Alarm 7, compressor 3 line 2
Baa98, Cba65 Alarm 1, compressor 4 line 2
Baa99, cba66 Alarm 2, compressor 4 line 2
Baaaa, Cba67 Alarm 3, compressor 4 line 2
Baaab, Cba68 Alarm 4, compressor 4 line 2
Baaac, Cba69 Alarm 5, compressor 4 line 2
Baaad, Cba70 Alarm 6, compressor 4 line 2
Baaae, Cba71 Alarm 7, compressor 4 line 2
Baaag, Cba78 Alarm 1, compressor 7 line 2
Baaah, Cba79 Alarm 2, compressor 7 line 2
Baaai, Cba84 Alarm 1, compressor 8 line 2
Baaaj, Cba85 Alarm 2, compressor 8 line 2
Baaak, Cba90 Alarm 1, compressor 9 line 2
Baaal, Cba91 Alarm 2, compressor 9 line 2
Baaam, Cba95 Alarm 1, compressor 10 line 2
Baaan, Cba99 Alarm 1, compressor 11 line 2
Baaao, Cbaad Alarm 1, compressor 12 line 2
Baaas, Cbaak Liquid level alarm, line 2
Condenser
Baadd Fan inverter warning, line 2
Baaaq Common high pressure switch, line 2
Baabn, Dba01 Fan circuit breaker 1, line 2
Baabo, Dba02 Fan circuit breaker 2, line 2
Baabp, Dba03 Fan circuit breaker 3, line 2
Baabq, Dba04 Fan circuit breaker 4, line 2
Baabr, Dba05 Fan circuit breaker 5, line 2
Baabs, Dba06 Fan circuit breaker 6, line 2
Baabt, Dba07 Fan circuit breaker 7, line 2
Baabu, Dba08 Fan circuit breaker 8, line 2
Baabv, Dba09 Fan circuit breaker 9, line 2
Baabw, Dba10 Fan circuit breaker 10, line 2
Baabx, Dba11 Fan circuit breaker 11, line 2
Baaby, Dba12 Fan circuit breaker 12, line 2
Baabz, Dba13 Fan circuit breaker 13, line 2
Baaca, Dba14 Fan circuit breaker 14, line 2
Baacb, Dba15 Fan circuit breaker 15, line 2
Baacc, Dba16 Fan circuit breaker 16, line 2
Baacd, Dba17 Common fan circuit breaker, line 2
