– 20 –
When you order parts, please make a photocopy of this page
and fill the number of the parts in the “Order” column.
INDOOR UNIT
PARTS LIST
Ref.
No.
Description
ASH9ASGCW ASH9RSGCW
Ord.
Q’ty
63 Front Panel 9305436019 9305436019 9305436019 9305436019
64 Capacitor (Fan Motor) 9700468103 9700468103 9700468103 9700468103
65 Flow Control Panel-Z 9305443017 9305443017 9305443017 9305443017
69 Louver-A 9305415014 9305415014 9305415014 9305415014
74 Filter 9305444014 9305444014 9305444014 9305444014
108 Base 9305427031 9305427031 9305427031 9305427031
109 Casing 9305411016 9305411016 9305411016 9305411016
122 Shaft Holder-B 9303066010 9303066010 9303066010 9303066010
127 Drain Hose Assy 9305550029 9305550029 9305550029 9305550029
146 Evaporator Assy 9308203021 9308555014 9308555014 9308555014
151 Control Box 9305448036 9305448036 9305448036 9305448036
158 Connecting Pipe Assy 9306416010 9306416010 9307073007 9307073007
163 Thermistor Spring 313104262701 313104262701 313104262701 313104262701
164 Fan Motor 9600917015 9600917015 9600917015 9600917015
169 Cross-flow Fan Assy 9307836015 9307836015 9307836015 9307836015
178 Motor Cushion-A 9306274009 9306274009 9306274009 9306274009
185 Wire Clamp 9305940004 9305940004 9305940004 9305940004
188 Power Cord Assy 9702595012 9702595012 9702595012 9702595012
195 Clamp SKB-100 313361275805 313361275805 313361275805 313361275805
196 Clamp SKB-150 313035356905 313035356905 313035356905 313035356905
233 Power Transformer 9701803026 9701565023 9701803026 9701803026
234 Thermistor Assy-(Room) 9702324018 9702324018 9702324018 9702324018
235 Thermistor Assy-(Pipe) 9702425012 9702425012 9702425012 9702425012
236 Controller PCB Assy 9702889036 9702884024 9702889043 9702884017
240 Remote Control Unit 9307113048 9307113055 9307113048 9307113055
281 Clamp Metal (Pipe) 9306192006 9305430000 9306192006 9305430000
282 Wall Cap-B (Accessory) 313714296205 313714296205 313714296205 313714296205
323 Louver-B 9305597017 9305597017 9305597017 9305597017
336 Suction Pipe-A Assy 9305741014 9305741014 9306175009 9306175009
385 Indicator PCB Assy 9701364213 9701364213 9701364213 9701364213
401 Wall Hook Bracket 9304358008 9304358008 9304358008 9304358008
425 Earth Terminal 9306483005 9306483005 9306483005 9306483005
440 Flow Control Panel-U 9306173012 9306173012 9306173012 9306173012
466 Clamp NK-4N 313714328805 313714328805 313714328805 313714328805
593 Discharge Pipe-A Assy 9306417017 9306417017 9306417017 9306417017
652 Thermistor Holder Pipe 313714262805 313714262805 313714262805 313714262805
743 Remote Control Holder Case 9305642014 9305642014 9305642014 9305642014
759 Intake Grille 9305441044 9305441044 9305441044 9305441044
760 Insulation (Pipe)-E 9304607007 9304607007 9304607007 9304607007
761 Side Cover-R 9305996018 9305996018 9305996018 9305996018
762 Side Cover-L 9305437047 9305437047 9305437047 9305437047
764 Drain Cap Assy 9304150008 9304150008 9304150008 9304150008
767-1 Bottom Cover-A 9305428038 9305428038 9305428038 9305428038
767-2 Bottom Cover-B 9305429035 9305429035 9305429035 9305429035
780 Key Top (Slide Switch) 9303526002 9303526002 9303526002 9303526002
815 Terminal-2P 9701955022 –––– 9701955022 ––––
815 Terminal-4P –––– 9701955039 –––– 9701955039
850 Window (Receiver) 9305439010 9305439010 9305439010 9305439010
872 Indicator Case 9305978014 9305978014 9305978014 9305978014
873 Lamp Cover 9305451012 9305451012 9305451012 9305451012
874 Control Box Cover 9305977017 9305977017 9305977017 9305977017
875 Power Supply PCB Assy 9702440213 9702440220 9702440213 9702440220
876-1 Step Motor 9305780006 9305780006 9305780006 9305780006
876-2 Step Motor –––– 9305892006 –––– 9305892006
928-1 U-Pipe (BB) 9305747009 9305747009 9305747009 9305747009
929-1 U-Pipe (V) 9305748006 9305748006 9305748006 9305748006
930-1 U-Pipe (W) 9305749003 9305749003 9305749003 9305749003
932 Outlet Cover 9305414017 9305414017 9305414017 9305414017
960 Diffuser 9305412013 9305412013 9305412013 9305412013
961 Guard Clamp 9306332013 9306332013 9306332013 9306332013
962-1 Guard Holder-L 9305753017 9305753017 9305753017 9305753017
962-2 Guard Holder-R 9305752010 9305752010 9305752010 9305752010
963 Fan Guard 9305751013 9305751013 9305751013 9305751013
964 Flare Nut-A 9307767005 9307767005 313996239804 313996239804
965 Flare Nut-B 9307768002 9307768002 9307768002 9307768002
966 Bonnet-A 9304798019 9304798019 –––– ––––
967-1 Bonnet-B 9304799016 9304799016 9304799016 9304799016
967-2 Bonnet-C –––– –––– 9306700010 9306700010
968 Relay PCB Assy 9702443214 9702443214 9702443214 9702443214
973 Gear Assy 9305452002 9305452002 9305452002 9305452002
974 Joint (Louver) 9305416011 9305416011 9305416011 9305416011
976 Window (Indicator) 9305440016 9305440016 9305440016 9305440016
B Machine Screw (with Spring Washer) 0700179013 0700179013 0700179013 0700179013
C Machine Screw (with Spring Washer) 301291134088 301291134088 301291134088 301291134088
Part No.
ASH9ASGCW
ASH9RSGCW
ASH12ASGCW
ASH12RSGCW
ASH12ASGCW ASH12RSGCW
