General-Fujitsu ASH9ASGCW [20/23] Outdoor unit continued

– 22 –

When you order parts, please make a photocopy of this page

and fill the number of the parts in the “Order” column.

OUTDOOR UNIT (Continued)

Ref.

No.

Description

AOH9ANGC AOH9RSGC

Ord.

Q’ty

674 Tapping Screw (Special) 9305848010 9305848010 9305848010 9305848010

688 Screw (with Square Washer) 313681304205 313681304205 313681304205 313681304205

765 Drain Pipe –––– 9301102000 –––– 9301102000

766 Drain Pipe Packing –––– 9301143003 –––– 9301143003

815 Terminal-2P 9306489014 –––– 9306489014 ––––

815 Terminal-4P –––– 9306488017 –––– 9306488017

820 Capillary Joint-BC Assy 9306134006 –––– 9306134006 ––––

916 Noise Insulation-G 9306098001 9306362003 9306362003 9306362003

935-1 Reinforcement (Cabinet Top) 9305973002 9305973002 9305973002 9305973002

935-2 Reinforcement-F (Cabinet Top) 9306123000 9306123000 9306123000 9306123000

942-1 Control Box Cover-A Metal 9308562012 9308562012 9308562012 9308562012

942-2 Control Box Cover-B Metal 9305975006 9305975006 9305975006 9305975006

946 Inlet Pipe –––– 9306401009 –––– ––––

982 Cord Clamp (Plastic, Black) 9302271002 9302271002 9302271002 9302271002

A Screw (with Inner Washer) 9357297002 9357297002 9357297002 9357297002

B Screw (with Spring Washer) 0700179013 0700179013 0700179013 0700179013

984 U Pipe (Y) D9.52 –––– –––– –––– 9305523009

Part No.

AOH12ASGC AOH12RSGC

Note : Always use specified screws, since Ref. No. 688, A, B and C are screws for the earth.

Ref. No.688 : Machine screw (with spring washer) M4 x P0.7 x L10, plating thickness 5µ or more.

A : Taapping screw (with inner clip washer) M4 x L10, plating thickness 5µ or more.

B : Machine screw (with spring washer) M4 x P0.7xL10, plating thickness 5µ or more.

C : Machine screw (with spring washer) M4 x P0.7xL8, plating thickness 5 µ or more.

AOH9ANGC

AOH9RSGC

AOH12ASGC

AOH12RSGC
