General-Fujitsu ASH9ASGCW [19/23] Outdoor unit
![General-Fujitsu ASH9ASGCW [19/23] Outdoor unit](/views2/1805598/page19/bg13.png)
– 21 –
When you order parts, please make a photocopy of this page
and fill the number of the parts in the “Order” column.
OUTDOOR UNIT
Ref.
No.
Description
AOH9ANGC AOH9RSGC
Ord.
Q’ty
4 Emblem-Rear 9306094003 9306094003 9306094003 9306094003
5 Cabinet Front Panel, Plastic 9305525010 9305525010 9305525010 9305525010
7 Connector Cover (Cabinet) 9306119010 9306119010 9306119010 9306119010
9 Cabinet Rear Panel, Plastic 9305526017 9305526017 9305526017 9305526017
12 Base Assy, Painted 9306118044 9306118020 9306118068 9306118020
13 3-Way Valve 9306801014 9306801014 9306802011 9306802011
14 2-Way Valve 9306800017 9306800017 9306800017 9306800017
16 Condenser Assy 9306415006 9306477004 9307276002 9306482008
18 Suction Pipe 9306041007 9307931000 9306358006 ––––
19 Capillary Tube 9306043001 –––– 9308226006 ––––
20 Discharge Pipe Assy 9306038007 9307035012 9306365004 9307036019
26-6 BR Sheet 100x120xT5 –––– 9305039029 –––– ––––
26-7 BR Sheet 30x120xT7 9305039036 9305039036 9305039036 9305039036
26-8 BR Sheet 65x170xT2 9305490011 9305490011 9305490011 ––––
26-9 BR Sheet 180x180xT2 –––– –––– –––– 9305039067
26-10 BR Sheet 100x160xT5 –––– –––– –––– 9305039074
26-11 BR Sheet 50x190xT3 –––– 9300389068 –––– 9300389068
32 Control Box Metal 9305972005 9305972005 9305972005 9305972005
34 Capacitor (Fan Motor) 9700468080 9700468097 9700468110 9700468097
37 Capacitor (Running) 9306512019 9306512019 9306512026 9306512019
38 Clamp Metal (Capacitor) 313468061808 313468061808 313468061808 313468061808
39 Propeller Fan 9305538003 9305538003 9305538003 9305538003
41 Fan Motor 9307095016 9307095016 9307715013 9306402013
42 Bracket (Motor) 9305536016 9305536016 9305536016 9305536023
46 Compressor Assy 9308230003 9308997005 9308228000 9306496005
47-2
Discharge Pipe Rubber (Pipe Absorber)
313185159802 –––– 313185159802 ––––
51 Special Nut M5 9300301015 313199233602 9307091001 313199233602
55 Special Nut M8 313252257701 313252257701 –––– 313252257701
62 Wire Assy (Shield)-A 9305695027 9305971026 9305695027 9305971026
98 Fan Ring 9305581023 9305581023 9305581023 9305581023
107 Rubber Seat-A 9351049010 9307092008 9307092008 9351813017
109 Terminal Cover (Comp.) 9351048013 9307090004 9307090004 9351120009
138 Separate Wall 9305971008 9305971008 9305971008 9305971008
155 Special Nut M6 –––– –––– 9307615016 ––––
187 Clamp No. 1219 313361271706 313361271706 313361271706 313361271706
195 Clamp SKB-100 313361275805 313361275805 313361275805 313361275805
196 Clamp SKB-150 313035356905 313035356905 313035356905 313035356905
196-2 Clamp SKB-3MC 9305335008 9305335008 9305335008 9305335008
227 OCR Spring (Comp.) 9351050016 –––– –––– ––––
230 Overload Relay 9306096007 –––– 93052453007 9306466008
300 Suction Pipe-C Assy –––– –––– –––– 9307932007
329 Coupling Pipe Assy –––– 9306400002 –––– ––––
329-2 Coupling Pipe-C –––– 9306433000 –––– 9306442002
343 Solenoid Coil –––– 9360538031 –––– 9360538031
344 4-Way Valve –––– 9307555015 –––– 9307556012
365 Bracket (Valve) 9306748012 9306748012 9306748012 9306748012
412 Terminal Gasket (Comp.) 9351051013 9307089008 9307089008 9351121006
420 Capillary Assy (with Check Valve) –––– 9308960009 –––– 9308325006
423 Noise Insulation-F 9306097004 9306424008 9306424008 9306424008
582 Discharge Pipe-SF 9306115005 –––– 9306115005 ––––
620 Inlet Pipe Assy –––– –––– –––– 9306394004
Part No.
AOH12ASGC AOH12RSGC
AOH9ANGC
AOH9RSGC
AOH12ASGC
AOH12RSGC
