General-Fujitsu ASH9ASGCW [21/23] Reverse cycle model

General-Fujitsu ASH12RSGCW [21/23] Reverse cycle model
– 23 –
Ref.
No.
Description
Ord.
Q’ty
IC1 IC MB89625R-SH-514 1301471018
IC2 IC NJM2904M 0100534054
IC3 IC MC1413D 0101736013
IC5 IC PST600CMT 0101461120
IC6 IC BR93LC46RF-E2 0100295016
Q1,2, 4~6 Xstr DTC124EK 0000517034
R1 Res. 1.5kΩ±5% 0200212784
R2,7,33~36 Res. 22kΩ±5% 0200213095
R3,9,13,26 Res. 1kΩ±5% 0200212746
R4 Res. 4.7kΩ±5% 0200212906
R5,11,12,14~ Res. 10kΩ±5% 0200213019
25,27,39,44,
46,47
R6 Res. 33kΩ±5% 0200213132
R8 Res. 1MΩ±5% 0200213491
R10 Res. 1.2kΩ±5% 0200731766
R32 Res. 100kΩ±5% 0200213255
R37 Res. 10kΩ±1% 0200279497
R38 Res. 49.9kΩ±1% 0200279824
R40 Res. 330Ω±5% 0200212623
R41~43 Res. 1.2kΩ±5% 0200708768
JC2~4,6~9, Res. 0Ω 0200230016
11~17,JP1~3
C1 Cap. Elec. 50V 10µF 0301192541
C2~5,8~16, Cap. Ceramic 25V 0.1µF 0300266748
18,19
C20,21 Cap. Ceramic 16V 1µF 0300316153
C22 Cap. Ceramic 50V 1000pF 0300308509
BZ1 Buzzer PKM13EPY-4000-TF01 9701298013
X1
Ceramic Resonator CST8.38MTW-TF01
0400061021
[ASH9ASGCW/ASH12ASGCW]
X1
Ceramic Resonator CST8.38MTW-TF01
1300116019
[ASH9RSGCW/ASH12RSGCW]
SW1 Key Switch EVQ-PFE-04R 9700891017
JP5~8,10 Wire IPS-3043-02 1903332014
CN1 Plug, PCB B5P-SHF-1AA 0500006069
CN2 Thermistor 150-103-86116 9702324018
CN3 Plug, PCB B2B-XH-AM 0500005321
CN4 Plug, PCB 53324-0710 0501052065
CN5 Plug, PCB 53325-1010 0501052591
CN7 Plug, PCB S3P-VH 0500011308
CN8 Plug, PCB B2B-XASK-1-A 0501045012
CN9 Plug, PCB 917072-7 0501065010
Part No.
CONTROLLER PCB ASSEMBLY (Ref. No. 236)
Ref.
No.
Description
Ord.
Q’ty
Part No.
When you order parts, please make a photocopy of this page
and fill the number of the parts in the “Order” column.
( ) : REVERSE CYCLE MODEL
Ref.
No.
Description
Ord.
Q’ty
IC102 IC NJM7805FA 0100462081
Q101 Xstr 2SD880 0000001014
D101 Diode S1VB20 0000292054
D102 Diode MTZJ15C 0000852203
D103~105 Diode 1SR139-400 0000353137
C101,102 Cap. Ceramic 4700pF 0300209110
C103,104 Cap. Plastic 250V 0.1µF 0300304075
C105 Cap. Elec. 35V 2200µF 0300331118
C106 Cap. Elec. 25V 2200µF 0300327111
C107~109 Cap. Elec. 50V 10µF 0301192541
C110 Cap. Ceramic 0.1µF 0300988251
SW101 Slide Switch 8SS1012-1 9701426010
VA101 Varistor ERZ-V10V471CS 0000515139
VA102 Arrester CP2470-F 9701835010
F101 Fuse BET 3.15A - 250V 0600222512
L101 Line Filter ELF15N015A 0400165118
(K101, 102) Relay G5N-1A 9701566013
(CR101, 102) CR Absorber RPEL-121204-C 9701125012
R101 Res.Carbon 1/4W 1kΩ ±5% 0201038758
R102 Res. Carbon 1/4W 10kΩ ±5% 0201005019
SSR101 Relay G3MB-202PL-VD 9702430016
HT101 Heat Sink 16 ∗ 25 9701675012
FH101,102 Fuse Holder PFC5000-0502 0500158072
CN101 Plug, PCB B3P5-VH-B 0500011735
CN102 Plug, PCB B2P3-VH-B 0500011728
CN103 Plug, PCB 53405-0210 0500940011
CN104 Plug, PCB B2B-XH-AM 0500005321
CN105 Plug, PCB 53406-9910 0500951048
CN106 Wire w/Connector L=100 9701424016
W101 Wire w/Terminal L=210 9701660018
(W102) Wire w/Terminal L=240 BLU 9701802012
W103 Wire w/Terminal L=225 BLK 9701657018
W104 Wire w/Terminal L=150 BRN 9701658015
(W105) Wire w/Terminal L=240 RED 9701802029
JM101, 104 Wire 0.6 mm dia. L=10 mm 9700025016
JM102 Wire Assembly IPS-1041-2 9700035015
JM103 Wire 0.6 mm dia. L=7.5 mm 9701076017
Part No.
POWER SUPPLY PCB ASSEMBLY (Ref. No. 875)
Ref.
No.
Description
Ord.
Q’ty
Part No.
D301 Diode 1SR139-400 0000353137
K301 Relay G4A-1A-PS 9701024018
CN301 Wire w/Connector L=140 9701279012
Ref.
No.
Description
Ord.
Q’ty
D201 Diode SLR-325VC RED 0000813259
D202 Diode SLR-325MC GRN 0000813242
D203 Diode SLR-325DC ORG 0000813235
C201 Cap. Ceramic 0.1µF 0300988251
C202 Cap. Elec. 25V 10µF 0300504413
X201 Remote Control Amplifier 0101525129
SBX1810-22
CN201 Wire w/Connector L=230 9701397013
Lamp Cover 9305451012
Part No.
INDICATOR PCB ASSEMBLY (Ref. No.385) RELAY PCB ASSEMBLY (Ref. No.968)
Ref.
No.
Description
Ord.
Q’ty
Part No.
ASH9ASGCW
ASH9RSGCW
ASH12ASGCW
ASH12RSGCW
