No. Port Function 0010400020 cooling only
0 Chip TMP87PH46N 1CA2
1 CN1 Primary side of transformer
RTB-1.5-2P
Without sequence
2 CN2 Second side of transformer
B3B-XH
Without sequence
3 CN3 Sensor B4B-XH 1 2-TM 3 4-EX
4 CN4 Outdoor unit wire B2P3-VH 1 3-N OF
5 CN5 Swing motor B5B-XH
1-12VDCˈ2~5-ABCD
6 CN6 Swing motor B5B-XH
1-12VDCˈ2~5-ABCD
7 CN7 Indoor fan motor B4P5-VH 1 2 3 5-H M L N
8 CN8 Receiver – opposite to the
sign B7B-XH
1-5VDCˈ~ˈ7-GND
9 CN9 Long distance B2B-XH-H
1-COMˈ2-GND
10 CN15 Crank -250 QZ
11 L Live wire -250 Relay
12 N Neutral wire -250 N
13 Fuze T3.15A 250VAC Have
14 R6 R13 RJ2002 R B B R BR
15 CT R20 fan motor stop: 13.5A
üü
Commercial Air Conditioner Model: HCFU-18/28CF03
HCFU-18/28HF03
74
