Haier HCFU-18CF03 [86/91] Commercial air conditioner
![Haier HCFU-28CF03 [86/91] Commercial air conditioner](/views2/1807718/page86/bg56.png)
R25=10K¡±3%
B25/50=3700K±3%
R25=10K¡±3%
B25/50=3700K±3%
T(ć)
Rnom(Kȍ) 11 18.43 43 4.93 71 1.9
-20ć
90.79 12 17.61 44 4.9 72 1.85
-19 85.72 13 16.83 45 4.58 73 1.79
-18 80.96 14 16.09 46 4.42 74 1.73
-17 76.51 15 15.38 47 4.26 75 1.68
-16 72.33 16 14.71 48 4.11 76 1.63
-15 68.41 17 14.08 49 3.97 77 1.58
-14 64.73 18 13.48 50 3.83 78 1.54
-13 61.27 19 12.9 51 3.7 79 1.49
-12 58.02 20 12.36 52 3.57 80 1.45
-11 54.97 21 11.84 53 3.45
-10 52.1 22 11.34 54 3.33
-9 49.4 23 10.87 55 3.22
-8 46.86 24 10.43 56 3.11
-7 44.46 25 10 57 3.11
-6 42.21 26 9.59 58 2.9
-5 40.08 27 9.21 59 2.81
-4 38.08 28 8.84 60 2.72
-3 36.19 29 8.48 61 2.63
-2 34.41 30 8.15 62 2.54
-1 32.73 31 7.83 63 2.49
0 31.14 32 7.52 64 2.38
1 29.64 33 7.23 65 2.3
2 28.22 34 6.95 66 2.23
3 26.4 35 6.68 67 2.16
4 25.61 36 5.43 68 2.09
5 24.41 37 5.6 69 2.03
6 23.27 38 5.59 70 1.96
7 22.2 39 5.73
8 21.18 40 5.52
9 20.21 41 5.32
10 19.3 42 5.12
Commercial Air Conditioner Model: HCFU-18/28CF03
HCFU-18/28HF03
86
