Silent The wind volume is SSLO after the compressor is on
hearing The wind volume will be kept SSLO within 20 seconds after the compressor
stops and then changes to weak
Silent The wind volume is SSLO
cooling
$LUFOHDQLQJ
ƵIf the blower fan starts working after receiving the remote-control order, the
aion generator starts working and sends out aions.
ƵThe aion generator stops as the blower fan stops.
ƵWhen the aion generator is OFF and the air cleaning function is on, the blower
fan starts running and the aion generator starts working again.
7LPHGUXQQLQJ
ƵSet the time duration according to the time difference between the clock for
timing and the current clock
Ƶ In timing mode, the display panel will flash the light at fixed times
7LPHG
When this function is set, operation modes on the panel display will not
OFF change. The timing icon will show and the operation stops when the set
time comes.
Timed When this function is on, the panel display will only display a question mark.
21
The unit will operate as the set mode when the time comes.
Timed The unit will start operating or stop according to the order of your setting.
ON/OFF
6OHHSLQJ5XQQLQJ
Cooling& When under the mode of cooling or moisture removing,the set temperature will
moisture rise by 1ć after 1 hour and another 1 ć after the next hour. 6 more hours
removing later the operation stops.
PRGH
KHDWLQJ
Under the heating mode,the set temperature will fall by 2ć every 1 hour
PRGH
within the first two hours . it will rise by 1 ć after another 3 hours and stop
afterrunning for 3 hours.
If the indoor blower fan is set to be strong wind before setting the
sleeping running, it will be medium wind afer setting the sleeping running. If
Indoor fan the indoor blower fan is set to be medium wind before setting the sleeping
Speed control running, it will be weak wind afer setting the sleeping running. If the indoor
blower fan is set to be weak wind before setting the sleeping running, the
running speed of the blower will not change.
$XWRPDWLFUXQQLQJPRGH
+6809,12H03/R(DB) Functions and control
Demastic Air Conditioners
18
