Haier HSU-09H03/R(DB) [76/131] Error codes and description indoor display
![Haier HSU-12H03/R(DB) [76/131] Error codes and description indoor display](/views2/1809710/page76/bg4c.png)
7.4.Error Codes and Description indoor display
Code Indication Description
Reference page
E1 Room temperature sensor failure
E2 Heat-exchange sensor failure
noitcnuflamrosnesytidimuH01E
Indoor
unit
E14 Indoor fan motor malfunction
F1 The protection of IPM
F3 Communication fault between the IPM and
outdoor PCB
F4 Overheat protection for exhaust temperature
F6 Ambient temperature sensor failure
F7 Suction temperature sensor failure
F21 Frost-removing temperature sensor failure
Outdoor
unit
F25 Exhaust temperature sensor failure
E7 Communication fault between the indoor and
outdoor units
System
noitcetorpesnetni-krowhgiH9E
The code indication that is listed above is the main fault
'HPDVWLF $LU &RQGLWLRQHUV
09,12H03 /R(DB)
System Diagnosis
74
74
79
78
76
75
82
81
81
81
81
84
86
