Installation of aesthetic panel

ʧ ʨFigure4a

2 Install the hook on the aesthetic panel and put the hook into the slot of the

outer door of dishwasher(see figure 4a). After positioning of the panel , fix the panel

onto the outer door by screws and bolts(See figure 4b) .

Installation of aesthetic panel

ʧ ʨFigure4b

. Take away the cover

. Pin up the screw

. Get back the cover

Furniture door

Hook for aesthetic door

Outer door of

dishwasher

Spacer for furniture door

Cover

4X18 screw

)PQ IPPL

4U DPVOUFSTVOL

IFBE TDSFX

-PXFS IPPL
