11
English
7. Confi rm that the battery is mounted correctly
8. Check the rotational direction
The bit rotates clockwise (viewed from the rear side) by
pushing the R-side of the selector button.
The L-side of the selector button is pushed to turn the
bit counterclockwise (See Fig. 9) (The
L
and
R
marks are provided on the body).
9. Switch operation
○ When the trigger switch is depressed, the tool rotates.
When the trigger is released, the tool stops.
○ The rotational speed of the drill can be controlled by
varying the amount that the trigger switch is pulled.
Speed is low when the trigger switch is pulled slightly
and increases as the trigger switch is pulled more.
NOTE
○ A buzzing noise is produced when the motor is about
to rotate; This is only a noise, not a machine failure.
10. Using the bit holder
CAUTION
○ Stow the bit in the specifi ed location on the tool. If the
tool is used with the bit stowed improperly, the bit may
fall and cause bodily injury.
○ Do not stow bits that are of a diff erent length, gauge
or dimension than the plus driver bit (65 mm long)
included in the STANDARD ACCESSORIES.
The bit may fall and cause bodily injury.
(1) Removing the bit
Securely hold the main unit and pull out the bit by
holding the tip with your thumb (Fig. 10).
(2) Installing the Bit
Install the bit with steps opposite of when removing.
Insert the bit so that the right and left sides are equal,
as shown in Fig. 11.
MAINTENANCE AND INSPECTION
1. Inspecting the tool
Since use of as dull tool will degrade effi ciency and
cause possible motor malfunction, sharpen or replace
the tool as soon as abrasion is noted.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws
be loose, retighten them immediately. Failure to do so
could result in serious hazard.
3. Cleaning on the outside
When the driver drill is stained, wipe with a soft dry
cloth or a cloth moistened with soapy water. Do not use
chloric solvents, gasoline or paint thinner, for they melt
plastics.
4. Storage
Store the driver drill in a place in which the temperature
is less than 40°C and out of reach of children.
5. Service parts list
CAUTION
Repair, modifi cation and inspection of Hitachi Power
Tools must be carried out by a Hitachi Authorized
Service Center.
This Parts List will be helpful if presented with the
tool to the Hitachi Authorized Service Center when
requesting repair or other maintenance.
In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
country must be observed.
MODIFICATIONS
Hitachi Power Tools are constantly being improved
and modifi ed to incorporate the latest technological
advancements.
Accordingly, some parts may be changed without prior
notice.
Important notice on the batteries for the
Hitachi cordless power tools
Please always use one of our designated genuine
batteries. We cannot guarantee the safety and
performance of our cordless power tool when used
with batteries other than these designated by us,
or when the battery is disassembled and modifi ed
(such as disassembly and replacement of cells or
other internal parts).
GUARANTEE
We guarantee Hitachi Power Tools in accordance with
statutory/country specifi c regulation. This guarantee does
not cover defects or damage due to misuse, abuse, or
normal wear and tear. In case of complaint, please send
the Power Tool, undismantled, with the GUARANTEE
CERTIFICATE found at the end of this Handling instruction,
to a Hitachi Authorized Service Center.
NOTE
Due to HITACHI’s continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
Information concerning airborne noise and vibration
The measured values were determined according to
EN60745 and declared in accordance with ISO 4871.
Measured A-weighted sound power level: 97 dB (A)
Measured A-weighted sound pressure level: 86 dB (A)
Uncertainty KpA: 3 dB (A).
Wear hearing protection.
Vibration total values (triax vector sum) determined
according to EN60745.
Vibration emission value
ah, D = 8.2 m/s
2
Uncertainty K = 1.5 m/s
2
WARNING
○ The vibration emission value during actual use of
the power tool can diff er from the declared value
depending on the ways in which the tool is used.
○ To identify the safety measures to protect the operator
that are based on an estimation of exposure in the
actual conditions of use (taking account of all parts of
the operating cycle such as the times when the tool is
switched off and when it is running idle in addition to
the trigger time).
