7
English
Model UC18YRL / UC18YFL
Charging time Approx. 20 – 50 minutes
Charging voltage 7.2 – 18 V
Weight 0.6 kg
SPECIFICATION
CHARGER
APPLICATION
For charging the HITACHI BATTERY
䡬 EB712S, EB7S, EB714S, FEB7S, EB7B,
EB912S, EB9S, EB914S, EB914, FEB9S, EB9B, EB924,
EB926H, EB930H, EB933X,
EB1212S, EB12S, EB1214S, EB1214L, FEB12S, EB12B,
EB1220BL, EB1224, EB1226H, EB1230H,
EB1230HL, EB1230X, EB1233X
EB1412S, EB1414S, EB1414, EB14B, EB1424,
EB1426H, EB1430H, EB1430X, EBL1430, EB1433X
EB1812S, EB1814SL, EB18B EB1820, EB1820L,
EB1824L, EB1826HL, EB1830H, EB1830HL, EB1830X,
EBM1830, EB1833X
2. Insert the battery into the charger.
Firmly insert the battery into the charger till it
contacts the bottom of the charger and checking
the polarities as shown in Fig. 1.
CAUTION:
䡬 If the batteries are inserted in the reverse direction,
not only recharging will become impossible, but it
may also cause problems in the charger such as
a deformed recharging terminal.
3. Charging
When inserting a battery in the charger, the charge
status lamp will light up continuously in red.
When the battery becomes fully recharged, the
charge status lamp will blink in red. (At 1-second
intervals.) (See Table 1)
(1) Lamp indication
The indications of the lamp will be as shown in
Table 1, according to the condition of the charger
or the rechargeable battery.
CHARGING
Before using the power tool, charge the battery as
follows.
1. Connect the charger’s power cord to the receptacle.
When connecting the plug of the charger to a
receptacle, the charge status lamp will blink in red.
(At 1-second intervals).
Table 1
Indications of the lamp
Before Blinks Lights for 0.5 seconds. Does not light
charging for 0.5 seconds. (off for 0.5 seconds)
Lights Lights continuously
Blinks Lights for 0.5 seconds. Does not light
for 0.5 seconds. (off for 0.5 seconds)
Flickers Lights for 0.1 seconds. Does not light
for 0.1 seconds. (off for 0.1 seconds)
■■■■■■■■■■■■■
Lights Lights continuously
Overheat
standby
Overheat
lamp
(green)
While
charging
Charging
complete
Charging
impossible
Battery overheated.
Unable to charge.
(Charging will
commence when
battery cools)
Charge
status lamp
(red)
Malfunction in the
battery or the charger
NOTE: When standby for cooling battery, UC18YRL cools the overheated battery by cooling fan.
