2 Product Description 2 1 Overview 1 Control panel 2 Shelf positions side racks if included 3 Wire shelves 4 Roasting dish 5 Fan if present 6 Oven door 7 Side racks if present only for flat cavity 2 2 Accessories according to the model Roasting dish Wire shelf For roasting and grilling Can be placed on a Holds baking trays and plates lower shelf to collect any food drips Side racks Telescopic guides only if present Located on both sides of the oven cavity holds metal grills and drip pans Two guide rails which facilitate the cooking status check as they allow easily the extraction and repositioning of dishes and shelves inside the oven cavity 2 3 First Use PRELIMINARY CLEANING Clean the oven before using for the first time Wipe over external surfaces with a damp soft cloth Wash all accessories and wipe inside the oven with a solution of hot water and washingup liquid Set the empty oven to the maximum temperature and leave on for about 1 hour this will remove any lingering smells of newness EN 15
