3. Use of the Oven
3.1 Display description
EN 16
1. Function selector knob
2. Cooking Time/End of cooking
3. Child Safety Lock
4. Minute minder
5. Clock setting
6. Temperature or clock display
7. LCD/temperature adjustment controls
8. Cooking function selector knob
2
4
5
1 8
6
7
WARNING : the first operation to carry out after the
oven has been installed or following the interruption of
power supply (this is recognizable by the display
pulsating and showing ) is setting the correct 12:00
time. The bottom right LED flashes at the same time
( ). This is achieved as follows.
•Rotate the left function selector to the position set the
Clock setting.
•Set time with "-" "+" buttons.
ATTENTION: The oven will only operate by setting the
clock.
3
