SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire electrical shock injury to persons or damage when using the oven follow the important safety instructions listed below Read all the instructions before using the oven Use the oven only for its intended purpose as described in these instructions Proper installation be sure your appliance is properly installed and earthed by a qualified technician Isolating switch make sure this oven is connected to a circuit which incorporates an isolating switch providing omnipolar disconnection from the power supply the device must have contact separation compliant to the requirements for overvoltage category III must bear the maximum connected load and in must be in line with current legislation The switch must be incorporated in the fixed wiring in accordance to the wiring rules The yellow green earth cable should not be interrupted by the device and must be easily accessible when the appliance is installed IF THE OVEN IS PROVIDED BY THE MANUFACTURER WITHOUT PLUG THE APPLIANCE MUST NOT BE CONNECTED TO THE POWER SOURCE USING PLUG OR SOCKETS BUT MUST BE DIRECTLY CONNECTED TO THE SUPPLY MAINS EN 06
