3.6. CS-F43DD3E5 CU-B43DBE8
ITEM / MODEL Indoor Unit Outdoor Unit
Main Body CS-F43DD3E5 CU-B43DBE8
Cooling Capacity kW 12.5
BTU/h 42,600
Heating Capacity kW 14.0
BTU/h 47,700
Refrigerant Charge-less m 30
Standard Air Volume for High Speed m
3
/min Hi 40 Hi 94
cfm Hi 1413 Hi 3316
External Static Pressure Pa Hi 50 -
mmAq Hi 5.1
Outside Dimension (H x W x D) mm 250 x 1200 x 650 1170 x 900 x 320
inch 9-27/32 x 47-7/32 x 25-19/32 46-1/16 x 35-7/16 x 12-19/32
Net Weight kg (lbs) 47 (104) 102 (225)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.53 (3/8) Flared Type
Drain mm Female screw RC1 (PT1) I.D Ø 20 x 1
Compressor Type, Number of Set - Hermetic, 1
Starting Method - Permanent Split Capacitor
Motor Type - 2-pole single phase brushless motor
Rated Output kW - 3.75
Fan Type, Number of Set Sirocco Fan, 3 Mix flow fan - 2
Motor Type 4-pole single phase induction motor 6-pole single phase induction motor
Rated Output kW 0.185 0.07 x 2
Air-heat Exchanger (Row x Stage x FPI) Louvre-fin type (3 x 16 x 15) Corrugate-fin type (2 x 44 x 20)
Refrigerant Control - Exp. Valve
Refrigerant Oil (Charged) cm
3
- FV68D (1500)
Refrigerant (Charged) R410A kg (oz) - 3.10 (109)
Running
Adjustment
Control Switch Wired Remote Control -
Room Temperature Thermostat -
Noise Level dB (A) Cooling : Hi 45 Lo 41 Cooling 56, Heating 57
Heating : Hi 44 Lo 40
Power level dB Cooling : Hi 60 Lo 56
Heating : Hi 59 Lo 55
Cooling 70, Heating 71
Moisture Removal L/h (Pt/h) 7.9 (16.6)
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50 Hz)
ITEM / MODEL Condition by ISO5151
Volts V 380 400 415
Phase 3N 3N 3N
Power Consumption kW Cool 4.75 4.8 4.87
Heat 4.61 4.68 4.78
Running Current A Cool 8.0 8.1 8.2
Heat 7.8 7.9 8.0
Starting Current A 54 57 60
Power Factor % Cool 90 86 83
Heat 90 86 83
EER W/W 2.63 2.60 2.57
COP W/W 3.04 2.99 2.93
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 3N~380V, 400V, 415V 50Hz
