3.2. CS-F28DD3E5 CU-B28DBE5
ITEM / MODEL Indoor Unit Outdoor Unit
Main Body CS-F28DD3E5 CU-B28DBE5
Cooling Capacity kW 7.3
BTU/h 24,900
Heating Capacity kW 8.0
BTU/h 27,300
Refrigerant Charge-less m 30
Standard Air Volume for High Speed m
3
/min Hi 22 Hi 63
cfm Hi 777 Hi 2226
External Static Pressure Pa Hi 50 -
mmAq Hi 5.1
Outside Dimension (H x W x D) mm 250 x 1000 x 650 795 x 900 x 320
inch 9-26/32 x 39-5/16 x 25-18/32 31-5/16 x 35-7/16 x 12-19/32
Net Weight kg (lbs) 41 (91) 69 (152)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.53 (3/8) Flared Type
Drain mm Female screw RC1 (PT1) I.D Ø 20 x 1
Compressor Type, Number of Set - Hermetic, 1
Starting Method - Permanent Split Capacitor
Motor Type - 2-pole single phase brushless motor
Rated Output kW - 2.2
Fan Type, Number of Set Sirocco Fan, 2 Mix flow fan - 1
Motor Type 4-pole single phase induction motor 6-pole single phase induction motor
Rated Output kW 0.085 0.07
Air-heat Exchanger (Row x Stage x FPI) Louvre-fin type (3 x 12 x 15) Corrugate-fin type (2 x 36 x 19)
Refrigerant Control - Exp. Valve
Refrigerant Oil (Charged) cm
3
- FV50S (1130)
Refrigerant (Charged) R410A kg (oz) - 2.05 (72)
Running
Adjustment
Control Switch Wired Remote Control -
Room Temperature Thermostat -
Noise Level dB (A) Cooling : Hi 43 Lo 39 Cooling 52, Heating 53
Heating : Hi 43 Lo 39
Power level dB Cooling : Hi 59 Lo 55
Heating : Hi 59 Lo 55
Cooling 67, Heating 68
Moisture Removal L/h (Pt/h) 4.3 (9.0)
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50 Hz)
ITEM / MODEL Condition by ISO5151
Volts V 220 230 240
Phase Single Single Single
Power Consumption kW Cool 2.78 2.84 2.89
Heat 2.61 2.69 2.78
Running Current A Cool 13.3 13.5 13.7
Heat 12.5 12.6 13.1
Starting Current A 62 65 68
Power Factor % Cool 95 91 88
Heat 95 93 88
EER W/W 2.63 2.57 2.53
COP W/W 3.07 2.97 2.88
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 1~220V, 230V, 240V 50Hz
