Unit CS-A24BK CU-A24BK
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (cm
3
) — SUNISO 4GDID or ATMOS
M60 (1,130)
Refrigerant (R-22) g (oz) — 1,770 (62.5)
Thermostat Electronic Control Mechanical Control
Protection Device — Inner Protector
Capillary Tube Length mm — Cooling; 663, Heating; 550
Flow Rate l/min — Cooling; 13.0, Heating; 29.0
Inner Diameter mm — Cooling; 1.6, Heating; 2.4
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 50 µF, 370VAC
Fan Motor Capacitor µF, VAC — 3.0 µF, 450VAC
Note:
•
Specifications are subject to change without notice for further improvement.
•
(1) — CS-A24BKP/CU-A24BKP5 (Europe).
•
(2) — CS-A24BKP-2/CU-A24BKP5-2 (Oceania).
•
(3) — CS-A24BKP-3/CU-A24BKP5-3 (Argentina).
•
(4) — CS-A24BKP-6/CU-A24BKP5-6 (Turkey).
11
CS-A18BKP CU-A18BKP5 / CS-A24BKP CU-A24BKP5
