16 Replacement Parts List
<Model: CS-A18BK / CS-A24BK>
REF. NO. PART NAME & DESCRIPTION QTY. CS-A18BK CS-A24BK REMARKS
1 CHASSY COMPLETE 1 CWD50C1178
←
2 FAN MOTOR 1 CWA981056
←
0
3 CROSS FLOW FAN COMPLETE 1 CWH02C1010
←
4 SCREW - CROSS FLOW FAN 1 CWH4580304
←
5 BEARING ASS’Y 1 CWH64K007
←
6 EVAPORATOR 1 CWB30C1125 CWB30C1129
7 FLARE NUT 1 CWH6002140 (1/4”)
←
8 FLARE NUT 1 CWT25007 (1/2”) CWT25004 (5/8”)
9 INTAKE AIR SENSOR HOLDER 1 CWH32142
←
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2102
←
11 VERTICAL VANE 16 CWE241088
←
12 CONNECTING BAR 1 CWE261025
←
13 AIR SWING MOTOR 1 CWA98260
←
0
14 AIR SWING MOTOR 1 CWA981041
←
0
15 LEAD WIRE - AIR SWING MOTOR 1 CWA67C3731
←
16 HORIZONTAL VANE 1 CWE241072
←
17 CAP - DRAIN TRAY 1 CWH52C1001
←
18 PARTICULAR PIECE 1 CWD932162
←
19 CONTROL BOARD 1 (1)
(2)
(3)
(4)
CWH102103
CWH102103A
CWH102103
CWH102103
←
←
←
←
20 TERMINAL BOARD COMPLETE 1 CWA28C2066 CWA28C2070 0
21 POWER SUPPLY CORD 1 (1)
(2)
(3)
(4)
CWA20C2163
CWA20C2163
CWA20C2215
CWA20C2163
CWA20C2164
CWA20C2164
CWA20C2216
CWA20C2164
22 ELECTRONIC CONTROLLER - MAIN 1 CWA742661 CWA742496 0
23 ELECTRONIC CONTROLLER - POWER 1 CWA742616
←
0
24 LEAD WIRE - FAN MOTOR 1 CWA67C3732 CWA67C3733
25 P.C.B. RECEIVER 1 CWA73C1124
←
26 ELECTRONIC CONTROLLER - INDICATOR 1 CWE39C1046
←
0
27 LEAD WIRE - INDICATOR 1 CWA67C3724
←
28 INDICATOR HOLDER 1 CWD932163
←
29 SENSOR COMPLETE 1 CWA50C608
←
0
30 CONTROL BOARD TOP COVER 1 CWH131091
←
31 CONTROL BOARD FRONT COVER 1 CWH131090
←
32 REMOTE CONTROL COMPLETE 1 CWA75C2189
←
0
33 FRONT GRILLE COMPLETE 1 CWE11C2330
←
34 INTAKE GRILLE 1 CWE221037
←
35 GRILLE DOOR 1 CWE141033
←
36 CONTROL PANEL 1 CWE312114
←
37 DECORATION BASE (R) 1 CWE351067
←
38 DECORATION BASE (L) 1 CWE351068
←
39 AIR FILTER 2 CWD001049
←
40 SCREW - FRONT GRILLE 3 XTT4+16C
←
41 CAP - FRONT GRILLE 3 CWH521062
←
42 DRAIN HOSE 1 CWH85287
←
43 AIR PURIFYING FILTER 1 CWMD00C0001
←
0
44 SOLAR DEODORIZING FILTER 1 CWMD00C0002
←
0
45 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067
←
46 INSTALLATION PLATE 1 CWH36K1007
←
(Note)
•
All parts are supplied from MACC, Malaysia (Vendor Code: 086).
•
“O” marked parts are recommended to be kept in stock.
•
(1) — CS-A18BKP, CS-A24BKP (Europe).
•
(2) — CS-A18BKP-2, CS-A24BKP-2 (Oceania).
•
(3) — CS-A18BKP-3, CS-A24BKP-3 (Argentina).
•
(4) — CS-A18BKP-6, CS-A24BKP-6 (Turkey).
72
CS-A18BKP CU-A18BKP5 / CS-A24BKP CU-A24BKP5
