240V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 5.26 3.99 1.66 4.91 3.82 1.78 4.57 3.67 1.91 4.16 3.49 2.06
19.0°C 5.30 1.81
19.5°C 5.77 4.17 1.69 5.40 4.01 1.82 5.02 3.86 1.94 4.56 3.67 2.10
22.0°C 6.29 4.33 1.72 5.88 4.16 1.85 5.47 4.01 1.98 4.97 3.83 2.13
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 5.26 3.99 1.61 4.91 3.82 1.73 4.57 3.67 1.86 4.16 3.49 2.00
19.0°C 5.30 1.76
19.5°C 5.77 4.17 1.64 5.40 4.01 1.77 5.02 3.86 1.89 4.56 3.67 2.04
22.0°C 6.29 4.33 1.67 5.88 4.16 1.80 5.47 4.01 1.92 4.97 3.83 2.08
220V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 5.26 3.99 1.58 4.91 3.82 1.69 4.57 3.67 1.81 4.16 3.49 1.96
19.0°C 5.30 1.72
19.5°C 5.77 4.17 1.60 5.40 4.01 1.73 5.02 3.86 1.85 4.56 3.67 1.99
22.0°C 6.29 4.33 1.63 5.88 4.16 1.76 5.47 4.01 1.88 4.97 3.83 2.03
240V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 6.62 5.02 2.63 6.18 4.81 2.83 5.75 4.62 3.02 5.23 4.39 3.26
19.0°C 6.67 2.87
19.5°C 7.26 5.25 2.68 6.79 5.05 2.88 6.32 4.86 3.08 5.74 4.62 3.32
22.0°C 7.92 5.45 2.73 7.40 5.24 2.93 6.88 5.05 3.14 6.26 4.82 3.38
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 6.62 5.02 2.56 6.18 4.81 2.76 5.75 4.62 2.95 5.23 4.39 3.18
19.0°C 6.67 2.80
19.5°C 7.26 5.25 2.61 6.79 5.05 2.81 6.32 4.86 3.01 5.74 4.62 3.24
22.0°C 7.92 5.45 2.66 7.40 5.24 2.86 6.88 5.05 3.06 6.26 4.82 3.30
220V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 6.79 5.14 2.38 6.34 4.93 2.56 5.90 4.74 2.74 5.36 4.50 2.96
19.0°C 6.84 2.60
19.5°C 7.45 5.39 2.43 6.96 5.17 2.61 6.48 4.98 2.79 5.89 4.74 3.01
22.0°C 8.12 5.59 2.47 7.59 5.37 2.66 7.06 5.18 2.84 6.42 4.94 3.07
TC - Total Cooling Capacity (kW) Indoor 27°C/19°C
SHC - Sensible Heat Capacity (kW) Outdoor 35°C/24°C
IP - Input Power (kW)
