13.2.4. Filter Cleaning Operation Setting
Choose the operation setting by pressing AUTO OFF/ON button.
• If there is no operation, or receives any remote control signal within 5 minutes, the setting mode quits.
13.3. Individual Correspondence Mode
Setting Operation
1 • Filter cleaning will run automatically after the air conditioner operation stops (air conditioner
is turned off using remote control).
• After the filter cleaning is completed, the air conditioner operation will remain off.
2** • Filter cleaning will run automatically before the air conditioner operation starts (air conditioner
is either turned on using remote control or turned on by the air conditioner timer).
• After the filter cleaning is completed, the air conditioner operation will start automatically.
3** • Filter cleaning will run automatically before the air conditioner operation starts (air conditioner
is turned on using remote control).
• After the filter cleaning is completed, the air conditioner operation will start automatically.
4 • Filter cleaning will run automatically after the air conditioner operation stops (air conditioner
is either turned off using remote control or turned off by the air conditioner timer).
• After the filter cleaning is completed, the air conditioner operation will remain off.
** The setting is valid only if the following conditions are fulfilled:
1. The air conditioner is turned off for at least 3 minutes.
2. The air conditioner has operated continuously for at least 2 hours in previous operation.
