Panasonic CU-XE12EKE [6/79] Note specifications are subject to change without notice for further improvement
![Panasonic CU-XE12EKE [6/79] Note specifications are subject to change without notice for further improvement](/views2/1832914/page6/bg6.png)
6
Note:
• Specifications are subject to change without notice for further improvement.
Air Circulation Description Cross-flow Fan Propeller Fan
Material ASG20K1 P.P
Motor Type Transistor (8-poles) Induction (8-poles)
Input W 44.3 61.3
Rated Output W 30 40
Fan Speed Low (Cool/Heat) rpm 800 / 850 —
Medium (Cool/Heat) rpm 980 / 1,050 —
High (Cool/Heat) rpm 1,170 / 1,280 790/800
SuperHigh (Cool/Heat) rpm 1,250 / 1,340 —
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium
Fin Type Slit Fin Corrugated Fin
Row / Stage (Plate fin configuration, forced draft)
2 / 15 2 / 24
FPI 20 17
Size (W u H u L) mm 610 u 315 u 25.4 718.4 u 504 u 36.4
689.8
Refrigerant Control Device — Exp. Valve
Refrigerations Oil
(cm
3
)
— RB68A (400)
Refrigerant (R410A) g (oz) — 930 (32.8)
Thermostat Electronic Control —
Protection Device — Electronic Control
Capillary Tube Length mm — —
Flow Rate I/min — —
Inner Diameter mm — —
Air Filter Material PET —
Style
Compressor Capacitor PF, VAC — —
Fan Motor Capacitor PF, VAC — —
Unit CS-XE9EKE CU-XE9EKE
