2.2. CS-XE12EKE CU-XE12EKE
Unit CS-XE12EKE CU-XE12EKE
Performance Test Condition EUROVENT/AS
Power Source (Phase, Voltage, Cycle) ø, V, Hz Single, 230 - 240, 50
Cooling Capacity kW 3.50 (0.60 - 4.00)
kcal/h 3,010 (520 - 3,440)
Heating Capacity kW 4.80 (0.60 - 6.70)
kcal/h 4,130 (520 - 5,760)
Moisture Removal l/h (Pint/h) 2.0 (4.2)
Airflow Method OUTLET SIDE VIEW TOP VIEW
INTAKE
Air Volume Lo
m
3
/min (cfm)
Cooling; 8.2 (290) —
Heating; 9.2 (320)
Me
m
3
/min (cfm)
Cooling; 10.1 (360) —
Heating; 10.8 (380)
Hi
m
3
/min (cfm)
Cooling; 11.9 (420) Cooling; 31.0 (1,090)
Heating; 12.7 (450)
SHi
m
3
/min (cfm)
Cooling; 12.6 (450) —
Heating; 13.2 (470)
Noise Level dB (A) Cooling; High 42 - 42, Low 29 - 29 Cooling; High 48 - 48
Heating; High 42 - 42, Low 33 - 33 Heating; High 50 - 50
Power level dB Cooling; High 53 - 53 Cooling; High 61 - 61
Heating; High 53 - 53 Heating; High 63 - 63
Electrical Data Input Power W Cooling; 880 (120 - 1,100)
Heating; 1,220 (115 - 1,840)
Running Current A Cooling; 4.1 - 4.0
Heating; 5.6 - 5.4
EER W/W (kcal/hW) Cooling; 3.98 (3.42)
COP W/W (kcal/hW) Heating; 3.93 (3.39)
Starting Current A 5.6
Piping Connection Port inch G ; Half Union 1/2” G ; 3-way valve 1/2”
(Flare piping) inch L ; Half Union 1/4” L ; 2-way valve 1/4”
Pipe Size inch G ; (Gas side) 1/2” G ; (Gas side) 1/2”
(Flare piping) inch L ; (Liquid side) 1/4” L ; (Liquid side) 1/4”
Drain Hose Inner diameter mm 16 —
Length m 0.65 —
Power Cord Length m 1.8 —
Number of core-wire
3 (1.5 mm
2
)
—
Dimensions Height inch (mm) 12 (305) 21 - 1/4 (540)
Width inch (mm) 34 - 1/4 (870) 30 - 23/32 (780)
Depth inch (mm) 9 - 1/32 (229) 11 - 3/8 (289)
Net Weight lb (kg) 29 (13.0) 82 (37)
Compressor Description — Hermetic Scroll
Motor Type — Brushless (4-poles)
Rated Output W — 750
Air Circulation Description Cross-flow Fan Propeller Fan
Material ASG20K1 P.P
Motor Type Transistor (8-poles) Induction (8-poles)
Input W 44.3 65.9
Rated Output W 30 40
Fan Speed Low (Cool/Heat) rpm 900 / 1,000 —
Medium (Cool/Heat) rpm 1,100 / 1,180 —
High (Cool/Heat) rpm 1,300 / 1,380 840/820
SuperHigh (Cool/Heat) rpm 1,380 / 1,440 —
