92
17.2. Sensible Capacity Chart
• CU-NE9MKE
• CU-NE12MKE
230V Outdoor Temp. (C)
Indoor wet
bulb temp.
30 35 40 46
TCSHCIPTCSHCIPTCSHCIPTCSHCIP
17.0C 2.48 1.88 0.49 2.32 1.80 0.53 2.16 1.73 0.57 1.96 1.65 0.61
19.0C 2.50 0.54
19.5C 2.72 1.97 0.50 2.55 1.89 0.54 2.37 1.82 0.58 2.15 1.73 0.63
22.0C 2.97 2.04 0.51 2.77 1.96 0.55 2.58 1.89 0.59 2.35 1.81 0.64
230V Outdoor Temp. (C)
Indoor wet
bulb temp.
30 35 40 46
TCSHCIPTCSHCIPTCSHCIPTCSHCIP
17.0C 3.47 2.63 0.83 3.24 2.52 0.90 3.02 2.43 0.96 2.74 2.30 1.03
19.0C 3.50 0.91
19.5C 3.81 2.76 0.85 3.56 2.65 0.91 3.31 2.55 0.98 3.01 2.43 1.05
22.0C 4.15 2.86 0.86 3.88 2.75 0.93 3.61 2.65 0.99 3.28 2.53 1.07
TC
SHC
IP
-
-
-
Total Cooling Capacity (kW)
Sensible Heat Capacity (kW)
Input Power (kW)
Indoor 27C/19C
Outdoor 35C/24C
