94
(NOTE)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 00029488).
• “O” marked parts are recommended to be kept in stock.
REF.
NO.
PART NAME & DESCRIPTION QTY. CS-NE9MKE CS-XE9MKE-5 CS-NE12MKE CS-XE12MKE-5 REMARKS
1 CHASSIS COMPLETE 1 CWD50C1599 CWD50C1605 CWD50C1599 CWD50C1605
2 FAN MOTOR 1 ARW6101CB O
3 CROSS FLOW FAN COMPLETE 1 CWH02C1076
4 BEARING ASS’Y 1 CWH64K007
5 SCREW - CROSS FLOW FAN 1 CWH551146
6 EVAPORATOR 1 CWB30C3074 CWB30C3323
7 FLARE NUT (LIQUID) 1 CWT251030
8 FLARE NUT (GAS) 1 CWT251031
9 HOLDER SENSOR 1 CWH32143
10 DISCHARGE GRILLE COMPLETE 1 CWE20C3137 CWE20C3247 CWE20C3137 CWE20C3247
11 VERTICAL VANE 11 CWE241350
12 CONNECTING BAR 1 CWE261152
13 CONNECTING BAR 1 CWE261153
14 CONNECTING BAR 1 CWE261154
15 CONNECTING BAR 1 CWE261155
16 FULCRUM 1 CWH621102
17 A.S.MOTOR, DC SINGLE 12V 300OHM 1 CWA981264
18 CAP - DRAIN TRAY 1 CWH521096
19 HORIZONTAL VANE 1 CWE24C1268 CWE24C1288 CWE24C1268 CWE24C1288
20 BACK COVER CHASSIS 1 CWD933233 CWD933233A CWD933233 CWD933233A
21 CONTROL BOARD CASING 1 CWH102370
22 TERMINAL BOARD COMPLETE 1 CWA28C2357 O
23 ELECTRONIC CONTROLLER - MAIN 1 CWA73C5748 CWA73C5749 O
24 ELECTRONIC CONTROLLER - POWER 1 CWA746253 O
25 ELECTRONIC CONTROLLER - INDICATOR 1 CWA745995 O
26 INDICATOR HOLDER 1 CWD933021
27 SENSOR COMPLETE 1 CWA50C2664 O
28 CONTROL BOARD FRONT COVER 1 CWH13C1183
29 CONTROL BOARD TOP COVER 1 CWH131350
31 REMOTE CONTROL COMPLETE 1 CWA75C3634 O
32 FRONT GRILLE COMPLETE 1 CWE11C5083 CWE11C5089 CWE11C5083 CWE11C5089 O
33 INTAKE GRILLE COMPLETE 1 CWE22C1678 CWE22C1677 CWE22C1678 CWE22C1677 O
34 GRILLE DOOR 1 CWE14C1029 CWE14C1038 CWE14C1029 CWE14C1038
35 E-ION FILTER 2 CWD00K1016
36 SCREW - FRONT GRILLE 2 XTT4+16CFJ
37 CAP - FRONT GRILLE 2 CWH521194 CWH521194A CWH521194 CWH521194A
38 DRAIN HOSE 1 CWH851173
39 INSTALLATION PLATE 1 CWH361097
40 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1705
41 E-ION AIR PURIFYING SYSTEM 1 CWD93C1090
42 ELECTRONIC CONTROLLER - HVU 1 CWA745348 O
43 ION GENERATOR 1 CWH94C0028
44 ELECTRONIC CONTROLLER - RECEIVER 1 CWA745288 O
45 OPERATING INSTRUCTION 1 CWF568114
46 INSTALLATION INSTRUCTION 1 CWF614897
47 INSTALLATION INSTRUCTION 1 CWF614898
48 INSTALLATION INSTRUCTION 1 CWF614899
49 INSTALLATION INSTRUCTION 1 CWF614900
50 INSTALLATION INSTRUCTION 1 CWF614901
51 COVER FOR RECEIVER (UPPER) 1 CWD933022
52 COVER FOR RECEIVER (BOTTOM) 1 CWD933209
