96
(NOTE)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 00029488).
• “O” marked parts are recommended to be kept in stock.
[PHAAM] Printed in Malaysia
FY1107-0
REF. NO. PART NAME & DESCRIPTION QTY. CU-NE9MKE CU-NE12MKE REMARKS
1 CHASSIS ASS’Y 1 CWD50K2202
2 ANTI-VIBRATION BUSHING 3 CWH50077
3 COMPRESSOR 1 5CS110XBD04 O
4 NUT-COMPRESSOR MOUNT 3 CWH56000J
5 CRANKCASE HEATER 1 CWA341072
6 SOUND PROOF MATERIAL 1 CWG302466
7 FAN MOTOR BRACKET 1 CWD541089
8 FAN MOTOR 1 ARW44W8P40AC O
9 SCREW - FAN MOTOR BRACKET 2 CWH551217
10 SCREW - FAN MOTOR MOUNT 4 CWH55252J
11 PROPELLER FAN ASSY 1 CWH03K1014
12 NUT - PROPELLER FAN 1 CWH56053J
13 CONDENSER COMPLETE 1 CWB32C2874
14 STRAINER 1 CWB111004
15 EXPANSION VALVE 1 CWB051016J
16 HOLDER - COUPLING 1 CWH351025
17 3 WAYS VALVE (GAS) 1 CWB011434 O
18 4-WAYS VALVE 1 CWB001037J
19 2 WAYS VALVE (LIQUID) 1 CWB021333 O
20 DISCHARGE MUFFLER 1 CWB121021
21 V-COIL COMPLETE 1 CWA43C2144J
22 V-COIL COMPLETE 1 CWA43C2058J
24 SENSOR COMPLETE 1 CWA50C2402 O
25 SENSOR CO.OUTDOOR DISCHRG TEMP 1 CWA50C2512 O
27 TERMINAL BOARD ASSY 1 CWA28K1110J O
29 REACTOR 1 G0C193J00003
31 ELECTRONIC CONTROLLER - MAIN 1 CWA73C5752R CWA73C5753R O
32 CRANKCASE HEATER 1 CWA341050
33 CONTROL BOARD COVER (TOP) 1 CWH131264
34 SENSOR CO.(OUTDOOR COMPRESSOR TEMP) 1 CWA50C2205 O
36 TERMINAL COVER 1 CWH171039A
37 NUT-TERMINAL COVER 1 CWH7080300J
38 SOUND PROOF BOARD 1 CWH151188
39 CABINET SIDE PLATE (R) 1 CWE04C1212
40 CABINET SIDE PLATE (L) 1 CWE041278A
41 HANDLE 1 CWE161010
42 WIRE NET 1 CWD041111A
43 CABINET FRONT PLATE CO. 1 CWE06C1136
44 CABINET TOP PLATE 1 CWE031014A
45 PLATE-C.B.COVER 1 CWH131301
46 CONTROL BOARD COVER COMPLETE 1 CWH13C1211
50 RECEIVER 1 CWB14011
51 HOLDER SENSOR 1 CWH321023
52 HOLDER SENSOR 2 CWH32143
