- 3
The appliance may only be connected to
an electrical supply which has been in-
stalled in accordance with IEC 60364.
The appliance may only be connected to
alternating current. The voltage must cor-
respond with the type plate on the appli-
ance.
For safety reasons, we recommend that
you operate the appliance only via a
earth-leakage circuit breaker (max.
30 mA).
Cleaning operations which produce oily
waste water, e.g. engine washes, under-
body washes, may only be carried out us-
ing washing stations equipped with an oil
separator.
This appliance was designed to be used
with detergents which are supplied or rec-
ommended by the manufacturer. The use
of other detergents or chemicals may
compromise the safety of the appliance.
Caution
Safety devices protect the user and must not
be modified or bypassed.
The appliance switch prevents unintentional
operation of the appliance.
This lock locks the lever of the trigger gun and
prevents the inadvertent start of the appli-
ance.
The overflow valve prevents the permissible
working pressure from being exceeded.
If the lever on the trigger gun is released the
pressure switch turns off the pump, the high-
pressure jet is stopped. If the lever is pulled
the pump is turned on again.
The high pressure hose is specially construct-
ed with reinforced walls to handle water pres-
sure up to 13 MPa (1900 psi) - it can be easily
damaged and should be stored carefully.
Do not kink.
Do not drive vehicles over the hose.
Do not expose the hose to sharp edges or
corners.
Misuse will lead to ballooning or premature
failure and will invalidate warranty.
Caution
Create stability for the appliance prior to all
work on or with the appliance to prevent acci-
dents or damage.
The stability of the appliance is warranted
when it is placed onto an even surface.
The scope of delivery of your appliance is il-
lustrated on the packaging. Check the con-
tents of the appliance for completeness when
unpacking.
In the event of missing accessories or any
transport damage, please contact your deal-
er.
These operating instructions describe the
maximum equipment. Depending on the mod-
el, there are differences in the scopes of deliv-
ery (see packaging).
Illustrations on Page 2
1 Coupling element for water connection
2 Quick coupling for high pressure hose
3 High pressure connection
4 Appliance switch "0/OFF“/ „I/ON“
5 Detergent Tank
6 Suction hose for detergent
7 Storage for trigger gun
8 Transport handle
9 Storage for high-pressure hose
10 Storage for accessories
11 Mains cable with mains plug
12 Water connection
13 Trigger gun
14 Lock trigger gun
15 High pressure hose
16 Spray lance with Dirtblaster
17 Spray lance with pressure regulation
(Vario Power)
18 Washing brush
Safety Devices
Power switch
Lock trigger gun
Overflow valve with pressure switch
High pressure hose
Prerequisites for the appliance's stability
Operation
Scope of delivery
Description of the Appliance
13EN
