ENGLISHen
10
equipment, such as those dust masks that are
specially designed to filter out microscopic
particles.
This also applies to dust from other materials such
as some timber types (like oak or beech dust),
metals, asbestos. Other known diseases are e.g.
allergic reactions, respiratory diseases. Do not let
dust enter the body.
Observe the relevant guidelines and national
regulations for your material, staff, application and
place of application (e.g. occupational health and
safety regulations, disposal).
Collect the particles generated at the source, avoid
deposits in the surrounding area.
Use suitable accessories for special work. In this
way, fewer particles enter the environment in an
uncontrolled manner.
Use a suitable extraction unit.
Reduce dust exposure with the following measures:
- do not direct the escaping particles and the
exhaust air stream towards yourself or nearby
persons or towards dust deposits,
- use an extraction unit and/or air purifiers,
- ensure good ventilation of the workplace and keep
it clean using a vacuum cleaner. Sweeping or
blowing stirs up dust.
- Vacuum or wash protective clothing. Do not blow,
beat or brush protective gear.
Transport of li-ion battery packs:
The shipping of li-ion battery pack is subject to laws
related to the carriage of hazardous goods (UN
3480 and UN 3481). Inform yourself of the currently
valid specifications when shipping li-ion battery
packs. If necessary, consult your freight forwarder.
Certified packaging is available from Metabo.
Only send the battery pack if the housing is intact
and no fluid is leaking. Remove the battery pack
from the machine for sending. Prevent the contacts
from short-circuiting (e.g. by protecting them with
adhesive tape).
See page 2.
1 Drill chuck / drill chuck sleeve*
2 Adjusting sleeve (torque control, maximum
torque) *
3Adjusting sleeve
(screw driving, drilling, impact drilling) *
4Adjusting sleeve
(torque limitation) *
5 Slide-switch (1st/2nd gear)
6 Rotation selector switch (direction of rotation
setting, transporting safety device)
7Trigger switch
8Handle
9LED lights
10 Battery pack release button
11 Battery pack *
12 Capacity and signal indicator *
13 Capacity indicator button *
14 Belt hook *
15 Bit depot *
16 Protective cap *
* equipment-specific
6.1 The machine's multifunctional
monitoring system
If the machine switches off automatically, the
machine electronics have activated automatic
protection mode. A warning signal sounds
(continuous beeping). The beeping stops after a
maximum of 30 seconds or when the trigger switch
(7) is released.
In spite of this protective function, overloading
is still possible with certain applications and
can result in damage to the machine.
Causes and remedies:
1. Battery pack almost flat (the electronics
prevent the battery pack from discharging totally
and avoid irreparable damage).
If one LED (12) is flashing, the battery pack is
almost flat. If necessary, press the button (13)
and check the LED lamps (12) to see the charge
level. If the battery pack is almost flat, it must be
recharged.
2. Long continuous overloading of the machine will
activate the temperature cut-out.
Leave the machine or battery pack to cool.
Note:
The machine will cool more quickly if you
operate it at idling speed.
3. If the current is too high (for example, if the
machine seizes continuously for long periods),
the machine switches off.
Switch off the machine at the trigger switch (7).
Then continue working as normal. Try to prevent
the machine from seizing.
6.2 Battery pack
Charge the battery pack before use.
Recharge the battery pack if performance
diminishes.
Instructions on charging the battery pack can be
found in the operating instructions of the Metabo
charger.
In case of Li-Ion battery packs with capacity and
signal display (12) (equipment-specific):
- Press the button (13), the LEDs indicate the
charge level.
- The battery pack is almost flat and must be
recharged if one LED is flashing.
Removing and inserting the battery pack
Removal:
press the battery pack release button (10)
and pull the battery pack (11) forwards
.
Insertion:
Slide the battery pack (11) in until it
engages.
5. Overview
6. Use
