5
ENGLISH
• Press the «ON/SPEED» button (15) to select the blades rota-
tion speed:
– «LOW» – low air flow speed;
– «MID» – medium air flow speed;
– «HIGH» – high air flow speed.
• Press the button (16) «SWING» to switch the 90° oscillation
operating mode of the fan on.
• To stop the oscillation, press the button (16) «SWING» again.
• To select the airflow mode, consequently press the button
(19) «MODE» on the remote control or the control panel
(8). You may choose three operation modes, the operation
modes are shown (23, 24, 25):
– «NORMAL» – simple ventilation, the indicator (23) is glow-
ing; the blades rotation speed depends on the selected
mode and is shown with the indicators (21) «HIGH-MID-
LOW».
– «NATURAL» – natural wind, the indicator (24) is glow-
ing; natural wind imitation mode, the air flow speed is
chaotically changing: from soft breeze to strong gusts
of wind.
– «SLEEP» –night mode, the indicator (25) is glowing; the
air flow speed is changing in cycles, constantly increasing
and decreasing.
• You can set the operation time of the fan sleep timer with
the button (17) «TIMER», one of four indicators (22) will be
glowing.
• You can set the fan operation time from 0.5 «0,5Н» hour to
7.5 «0,5Н-1Н-2Н-4Н» hours (with 0.5 hour setting step).
• One of four indicators (22) will show the selected operation
time of the timer.
• To switch the timer off press the button (17) «TIMER» repeat-
edly until all the indicators (22) go out.
• To switch the fan off press the button (18) «OFF».
• You may change the position of the motor unit (7) of the fan
in accordance with the required air flow angle in the vertical
position, the fan slope angle is set manually. To change the
fan slope angle press with a slight effort on the motor unit (7)
upwards or downwards. Clicking while the fan is being tilted
is normal.
USING THE REMOTE CONTROL (20)
ATTENTION!
Batteries leakage can cause injuries or damage the unit. To
avoid the unit damage, follow the instructions given below:
– use only the «AAA» batteries;
– do not use old and new batteries at the same time or differ-
ent types of batteries;
– do not recharge the batteries;
– insert the batteries strictly following the polarity;
– remove the batteries if you are not planning to use the unit
for a long time;
– replace the batteries in time.
– apply to specialized centers for further recycling of the bat-
teries;
– avoid the power nippers circuit.
To use the remote control (RC) (20) open the battery compart-
ment lid and insert 2 «AAA» batteries (not supplied with the unit)
into the battery compartment strictly following the polarity, close
the battery compartment lid. If you do not use the unit for a long
time, remove the batteries from the battery compartment of the
remote control (20).
Note: – the buttons on the remote control (20) fully correspond
with the buttons on the control panel (8).
MAINTENANCE AND CARE
• Before cleaning the fan switch it off by pressing the button
(18) «OFF» or the button (18) «OFF» on the remote control
(20) and unplug it.
• Do not use abrasive cleaners and solvents to clean the unit.
• Clean the motor unit (7) with a slightly damp cloth, and then
wipe it dry.
• If you need to clean the blades (4), open the clamps of the
rear grid (6), remove the front grid (1) and then wipe the
blades (4) with a slightly damp cloth.
• Install the front grid (1) back to its place and close the
clamps.
• You may clean the fan blades with a vacuum cleaner using a
proper attachment.
• Do not immerse the motor unit (7) of the fan into water or any
other liquids. Make sure that no liquids get into the motor unit
(7) of the fan to avoid its damage and prevent risk of electric
shock.
STORAGE
– Unplug the fan and clean it.
– If necessary, dismantle the fan.
– Open the clamps on the rear grid (6), remove the front grid
(1), unscrew the blade clamp (3) by turning it clockwise,
remove the blades (4), unscrew the fixing nut of the rear grid
(6) and remove the grid (6).
– Unscrew the clamp (9) and remove the motor unit (7) from
the telescopic bar (10).
– Unscrew the clamp (14) and remove the bar (12) from the
crossed floor support (13).
– Pack the fan into the original package and put it away for
storage in a dry cool place away from children and disabled
persons.
DELIVERY SET
Motor unit – 1 pc.
Front grid – 1 pc.
Blade clamp – 1 pc.
Blades – 1 pc.
Rear grid – 1 pc.
Telescopic bar with the clamp – 1 pc.
Crossed floor support – 1 pc.
Remote control – 1 pc.
Warranty certificate – 1 pc.
Instruction manual – 1 pc.
TECHNICAL SPECIFICATIONS
Power supply: 220-240 V ~ 50 Hz
Rated input power: 40 W
Diameter: 40 cm (16”)
Remote control: 3 V 2 «AAA» batteries 1.5 V (not supplied)
RECYCLING
For environment protection do not throw out the unit and the bat-
teries (if included), do not discard the unit and the batteries with
usual household waste after the service life expiration; apply to
specialized centers for further recycling.
The waste generated during the disposal of the unit is subject to
mandatory collection and consequent disposal in the prescribed
manner.
For further information about recycling of this product apply to a
local municipal administration, a disposal service or to the shop
where you purchased this product.
The manufacturer preserves the right to change design, struc-
ture and specifications not affecting general principles of the
unit operation without a preliminary notification due to which
insignificant differences between the manual and product may
be observed. If the user reveals such differences, please report
them via e-mail info@coolfort.ru for receipt of an updated
manual.
Unit operating life is not less than 3 years
Guarantee
Details regarding guarantee conditions can be obtained from the
dealer from whom the appliance was purchased. The bill of sale
or receipt must be produced when making any claim under the
terms of this guarantee.
This product conforms to the EMC Directive 2014/30/
EU and to the Low Voltage Directive 2014/35/EU.
