English
KEY
T
O SYMBOLS
Symbols
These symbols are on the machine and in the instr
uctions.
WARNING! Careless or incorrect use can
result in serious or fatal injury to the
operator or others.
Please read the operator’s manual
carefully and make sure you understand
the instructions before using the machine.
Use a helmet with hearing protector
This product is in accordance with applicable
EC directives.
Reverse
Neutral
Fast forward
Slow forward
Fast
Slow
Warning: rotating parts. Keep hands and
feet clear.
The ignition lead should always be
removed from the spark plug before repair,
cleaning or maintenance work.
Keep your distance!
Explanation of warning le
vels
The w
arnings are graded in three levels.
W
ARNING!
IMPORTANT!
CAUTION!
!
W
ARNING! Used if there is a risk of serious
injury or death for the operator or damage to
the surroundings if the instructions in the
manual are not followed.
IMPOR
TANT! Used if there is a risk of injury to the operator
or damage to the surroundings if the instructions in the
manual are not followed.
CAUTION! Used if there is a risk of damage to materials or
the machine if the instructions in the manual are not
followed.
