ASSEMBLING AND ADJUSTMENTS
Unpac
king
Illustration:
1 • 1
Assemb
ly
Illustration:
1 • 2
Fitting the tine blades Illustrations only shows assembly of
the tin blades on the right side. Make sure that the sharp
edges face one side on both right and left side tines.
(Figure 1 - 6)
Fitting the support wheel.
(Figure 7)
Fitting the connecting joint.
(Figure 8)
Fitting the drag bar.
(Figure 9)
Fitting the handle bar.
(Figure 10)
Adjust the hight of the handle and tighten the knobs
securely.
(Figure 11)
Fitting the clutch control.
(Figure 12)
-
Turn to proper side and fasten the bolt.
Fitting the lower tidy cover.
(Figure 13 - 14)
-
Tidy the cables.
- Fit the rubber holder properly.
- Fit the cover and tighten the screws.
Fitting the tine cover.
(Figure 15 - 17)
- Do not tighten the bolt immediately after installed.
- Install all 4 bolts and n
uts first, then tighten one by one.
Fitting the shifting lever.
(Figure 18)
An
y dismantling operation must only be performed by an
authorized service workshop.
Description of the components
Illustration:
1 • 3
1
Engine
2 Tine cover
3 Support wheel
4 Belt cover
5 Blade round
6 Drag bar
7 Handle
8 Lever shifting
9 Bumper
10 Clutch control
11 ON/OFF switch
12 Throttle control
13 Upper tidy cover
14 Lower tidy cover
T
ype plate
Illustration:
1 • 4
T
ransport wheel
Illustration:
1 • 5
A=
Working position
B= Transport position
IMPORTANT! Make sure to not cut the cables or scratch the
machine when cutting the edges of the case.
Ref
erences Content of the case
A
Engine par
ts
B Holder comp
C Holder main comp
D Support wheel
E Drag bar
F Tine cover
G Tine cover bracket
H Lever shifting
I Blade
J Blade round
K Connector joint
L Cover lower tidy
M Tool bag
N Hardware bag
O Hardware bag tines only
!
W
ARNING! Inappropriate assembly of this
rotary tiller could cause severe injuries.
Ensure that you follow all the instructions
carefully.
CA
UTION! After assembling the machine completly, tighten
the bolts and screws with modertion. Do not overtighten.
