Husqvarna TF 338 [13/36] Assembling and adjustments

English

– 6

ASSEMBLING AND ADJUSTMENTS

Unpacking

Illustration: 1 • 1

Assembly

Illustration: 1 • 2

• Fitting the tine blades Illustrations only shows assembly of

the tine blades on the right side. Make sure that the sharp

edges face one side on both right and left side tines. There

is one piece of short blade on each side that need bending

to the gearbox when assembling.

(Figure 1 - 6)

• Fitting the connecting joint.

(Figure 7)

• Fitting the drag bar.

(Figure 8)

• Fitting the handle bar.

(Figure 9)

• Adjust the hight of the handle and tighten the knobs

securely.

(Figure 10)

• Fitting the clutch control.

(Figure 11)

- Turn to proper side and fasten the bolt.

• Fitting the lower tidy cover.

(Figure 12 - 13)

- Tidy the cables.

- Fit the rubber holder properly.

- Fit the cover and tighten the screws.

• Fitting the tine cover.

(Figure 14 - 16)

- Do not tighten the bolt immediately after installed.

- Install all 4 bolts and nuts ﬁrst, then tighten one by one.

• Fitting the shifting lever.

(Figure 17)

Any dismantling operation must only be performed by an

authorized service workshop.

Description of the components

Illustration: 1 • 3

1 Engine

2 Tine cover

3 Lower tidy cover

4 Belt cover

5 Blades

6 Drag bar

7 Handle

8 Lever shifting

9 Bumper

10 Clutch control

11 Throttle control

12 ON/OFF switch

13 Upper tidy cover

Type plate

Illustration: 1 • 4

1 Serial number

2 Article number

3 Tilling scope

4 Gear shifting

5 Engine displacement

6 Engine oil Quality (viscosity):

7 Engine oil capacity

8 Gear box oil quality

9 Gear box oil capacity

10 Nominal power

11 Net weight

12 Fuel

Transport wheel

Illustration: 1 • 5

Change the tines to wheels when transporting.

For more information about moving of the machine, see

section "Moving".

IMPORTANT! Make sure to not cut the cables/wires or

scratch the machine when cutting the edges of the case.

References Content of the case

A Engine parts

B Holder comp

C Holder main comp

D Lower tidy cover

E Drag bar

F Tine cover

G Tine cover bracket

H Lever shifting

I Blades

J Wheel

K Connector joint

L Tool bag

M Hardware bag tines only

N Hardware bag

WARNING! Inappropriate assembly of this

rotary tiller could cause severe injuries.

Ensure that you follow all the instructions

carefully.

CAUTION! After assembling the machine completly, tighten

the bolts and screws with modertion. Do not overtighten.
