TING AND ST

OPPING

Bef

ore starting

•

Check the engine oil level and top up if necessary.

Illustration: 2 • 1

•

Check the oil level of the gear box, and top up if

necessary.

Illustration: 2 • 2

• Check the fuel level. Fill if necessary. Illustration: 2 • 3

- Recommended to use: Octane Value over 90.

• Oiling the air ﬁlter Illustration: 2 • 4

Star

t the machine.

•

Open the fuel tap. Illustration: 2 • 5

• Set the choke control in the A position. Illustration: 2 • 6

• Throttle control Illustration: 2 • 7

- Push the throttle control to full throttle position.

• Set the on/off switch to ON to attain start throttle setting.

Illustr

ation: 2 • 8

•

Shifting lever Illustration: 2 • 9

- Put the gear shift lever in the ”N” position (neutral).

• Pull the recoil start handle Illustration: 2 • 10

• Set the choke control in the B position. Illustration: 2 • 11

Use

Forwar

Illustration: 3 • 1

• Use the shifting lever to control the drive speed.

Slow

Fast

• Press down the trigger lock on the handle (A) and push

the clutch lever in to

wards the handle (B).

• The cultivator starts to rotate when you push the clutch lever

down tow

ards the handle and stops rotating when you

release the clutch lever.

Reverse

Illustration: 3 • 2

• Slide the control to ”R” position.

• Press down the trigger lock on the handle (A) and push

the clutch lever in to

wards the handle (B).

Stopping

• Release the clutch lever. Illustration: 4 • 1

• Put the gear shift lever in the ”N” position (neutral).

Illustration: 4 • 2

•

Move the throttle control to the MIN. position. Illustration:

4 • 3

• Use the stop switch to switch off the engine. Illustration: 4

• 4

• Close the fuel tap. Illustration: 4 • 5

Moving the machine

Illustration: 5 • 1

• The engine must be switched off before moving. See

instructions under section Stopping.

• Change the blades to wheels when transporting.

(Figure

• Lift the drag bar from the ground using the handlebar and

then advance forwards.

(Figure B)

WARNING! When the machine starts, remain

within the safety zone.

WARNING! Keep unauthorised persons at a

distance. Children, animals, onlookers and

helpers should be kept outside the safety

zone of 20 m. Stop the machine immediately

if anyone approaches.

IMPORTANT! The cultivator starts to rotate when you push

the clutch down towards the handle and stops rotating

when you release the clutch. It is important to release the

clutch lever before using reverse.

WARNING! The use of reverse is dangerous!

Ensure that there are no obstacles behind

you and reduce the engine revs before

engaging the clutch.
