7
Assembly
Your generator is ready for use after it has been properly serviced with the
recommended fuel and oil.
If you have any problems with the servicing of your generator, contact your local Briggs
& Stratton service center. If you need assistance, please have the model, revision, and
serial number from the identification label available. See Features and Controls for
identification label location.
Unpack Generator
1. Set the carton on a rigid, flat surface.
2. Remove everything from carton.
The generator is supplied with:
• Operator’smanual
Add Engine Oil
1. Place generator on a level surface.
2. Add engine oil as described in Adding Engine Oil of the Engine
Maintenance section.
NOTICE
Improper treatment of generator could damage it and shorten its life.
• DONOTattempttocrankorstarttheenginebeforeithasbeenproperly
serviced with the recommended oil. This could result in an engine failure.
Add Fuel Figure
1
Fuel must meet these requirements:
• Clean,fresh,unleadedpetrol.
• Aminimumof87octane/87AKI(91RON).Forhighaltitudeuse,seeHigh
Altitude.
• Petrolwithupto10%ethanol(gasohol)orupto15%MTBE(methyltertiary
butyl ether) is acceptable.
NOTICE Avoid generator damage.
Failure to follow Operator’s Manual for fuel recommendations voids warranty.
• DONOTuseunapprovedpetrolsuchasE85.
• DONOTmixoilinpetrol.
• DONOTmodifyenginetorunonalternatefuels.
To protect the fuel system from gum formation, mix in a fuel stabilizer when adding
fuel. See Storage. All fuel is not the same. If you experience starting or performance
problems after using fuel, switch to a different fuel provider or change brands. This
engine is certified to operate on petrol. The emission control system for this engine is
EM (Engine Modifications).
1. Clean area around fuel fill cap, remove cap.
2. Slowly add unleaded fuel (A) to fuel tank (B). Be careful not to fill above the
baffle (C). This allows adequate space for fuel expansion as shown.
3. Install fuel cap and let any spilled fuel evaporate before starting engine.
High Altitude
Ataltitudesover1500meters(5,000feet),aminimum85octane/85AKI(89
RON) petrol is acceptable. To remain emissions compliant, high altitude adjustment
is required. Operation without this adjustment will cause decreased performance,
increased fuel consumption, and increased emissions. See a Briggs & Stratton
Authorized Dealer for high altitude adjustment information. Operation of the engine at
altitudes below 750 meters (2,500 feet) with the high altitude kit is not recommended.
Features and Controls Figure
2
Read this Operator’s Manual and safety rules before operating your
generator. Compare the illustrations with your generator, to familiarize
yourself with the locations of various controls and adjustments. Save this
manual for future reference.
A - Fuel Tank — Capacity of 15 liters (four (4) U.S. gallons) for 3750A generator.
Capacity of 25 liters (seven (7) U.S. gallons) for 6250A generator.
B - Hour Meter — Displays and records how many hours your generator has run (up
to 9,999.9). Helpful to ensure routine maintenance is performed on schedule.
C - Circuit Breakers (AC) — The receptacles are provided with circuit breakers to
protect the generator against electrical overload.
D - 230 Volt AC Outlets — May be used to supply electrical power for the operation
of230VoltAC,singlephase,50Hzelectrical,lighting,appliance,tool,andmotor
loads.
E - Oil Fill Cap — Check and add engine oil here.
F - Oil Drain Plug — Drain engine oil here.
G - Spark Arrester Muffler — Exhaust muffler lowers engine noise and is equipped
with a spark arrester screen.
H - Engine Identification (stamped on side) — Provides model, type and code of
engine. Please have these readily available if calling for assistance.
J - Grounding Fastener — Consult your local agency having jurisdiction for grounding
requirements in your area.
K - Identification Label — Provides model and serial number of generator. Please
have these readily available if calling for assistance.
L - Air Cleaner — Protects engine by filtering dust and debris out of intake air.
M - Choke Lever — Used when starting a cold engine.
N - Recoil Starter — Used to start the engine manually.
P - Engine Rocker Switch — Set this switch to on position (I) before using recoil
starter. Set switch to off position (O) to switch off engine.
R - Fuel Valve — Used to turn fuel supply on and off to engine.
WARNING Fuel and its vapors are extremely flammable and explosive which
could cause burns, fire or explosion resulting in death, serious
injury and/or property damage.
WHEN ADDING FUEL
• TurngeneratorengineOFFandletitcoolatleast2minutesbeforeremovingfuel
cap. Loosen cap slowly to relieve pressure in tank.
• Fillfueltankoutdoors.
• DONOToverfilltank.Allowspaceforfuelexpansion.
• Iffuelspills,waituntilitevaporatesbeforestartingengine.
• Keepfuelawayfromsparks,openflames,pilotlights,heat,andotherignition
sources.
• Checkfuellines,tank,capandfittingsfrequentlyforcracksorleaks.Replaceif
necessary.
• DONOTlightacigaretteorsmoke.
