Operation
Grounding Fastener
The generator is provided with a grounding fastener. Local electrical codes may
require this to be connected to a suitable earth connection. The generator neutral
is floating, which means that the AC stator winding is isolated from the grounding
fastener and the AC receptacle ground pins. Electrical devices, such as RCD,
requiring a grounded neutral may not operate properly from this generator.
Special Requirements
There may be Federal, local codes, or ordinances that apply to the intended use of
the generator. Please consult a qualified electrician, electrical inspector, or the local
agencyhavingjurisdiction:
• Thisgeneratorhasafloatingneutralandisnotforuseonjobsitesrequiring
a bonded neutral.
Generator Location Figure
3
Clearances and Air Movement
Place generator outdoors in an area that will not accumulate deadly exhaust gas. DO
NOT place generator where exhaust gas (A) could accumulate and enter inside or be
drawn into a potentially occupied building. Ensure exhaust gas is kept away from any
windows, doors, ventilation intakes, or other openings that can allow exhaust gas
to collect in a confined area. Prevailing winds and air currents should be taken into
consideration when positioning generator.
Starting the Engine Figure
2
Disconnectallelectricalloadsfromthegenerator.Usethefollowingstartinstructions:
1. Make sure unit is on a flat, level surface.
NOTICE Failure to start and operate the unit on a flat, level surface will cause the unit
not to start or shut down during operation.
2. Turn the engine rocker switch (2, N) to the on position (I).
3. Turn fuel valve (2, P) to on position (I).
4. Push choke lever (2, L) to choke position (
).
5. Grasp recoil handle (2, M) and pull slowly until slight resistance is felt. Then pull
rapidly to start engine.
• Ifenginestarts,proceedtostep7.
• Ifenginefailstostart,proceedtostep6.
6. Move choke lever to half choke position, and pull recoil handle twice.
• Ifenginefailstostart,repeatsteps4thru5.
7. Slowly move choke lever to run position (
). If engine falters, move choke
lever to half choke position until engine runs smoothly, and then to run position
(
).
NOTICE If engine floods, move choke lever to run position (
) and crank until
engine starts.
NOTICE If engine starts after 3 pulls but fails to run, or if unit shuts down during
operation, make sure unit is on a level surface and check for proper oil level in
crankcase. This unit is equipped with a low oil protection device. If so, oil must be at
proper level for engine to start.
Connecting Electrical Loads
Useonlyhighquality,well-insulatedextensioncableswiththegenerator’s230Volt
AC outlets. Inspect extension cables before each use. Check that all extension cables
are suitably rated and are not damaged. Keep extension cables as short as possible to
minimize voltage drop.
1. Let engine stabilize and warm up for a few minutes after starting.
2. Pluginandturnonthedesired230VoltAC,singlephase,50Hzelectricalloads.
NOTICE
• DONOTconnect3-phaseloadstothegenerator.
• DONOTconnect60Hzloadstothegenerator.
• DONOTOVERLOADTHEGENERATOR.SeeDon’t Overload Generator.
NOTICE Exceeding generators wattage/amperage capacity could damage generator
and/or electrical devices connected to it.
• DO NOT exceed the generator’s wattage/amperage capacity. See Don’t Overload
Generator in the Operation section.
• Startgeneratorandletenginestabilizebeforeconnectingelectricalloads.
• ConnectelectricalloadsinOFFposition,thenturnONforoperation.
• TurnelectricalloadsOFFanddisconnectfromgeneratorbeforestoppinggenerator.
WARNING Exhaust heat/gases could ignite combustibles, structures or
damage fuel tank causing a fire, resulting in death, serious
injury and/or property damage.
Contact with muffler area could cause burns resulting in
serious injury.
• DONOTtouchhotpartsandAVOIDhotexhaustgases.
• Allowequipmenttocoolbeforetouching.
• Keepatleast1.5m(5ft.)ofclearanceonallsidesofgeneratorincludingoverhead.
• Contacttheoriginalequipmentmanufacturer,retailer,ordealertoobtaina
spark arrester designed for the exhaust system installed on this engine.
• Replacementpartsmustbethesameandinstalledinthesamepositionas
the original parts.
WARNING
Generator voltage could cause electrical shock or burn resulting
in death or serious injury.
• DONOTconnectgeneratortoabuilding’selectricalsystem.
• DONOTtouchbarewiresorreceptacles.
• DONOTusegeneratorwithelectricalcordswhichareworn,frayed,bareor
otherwise damaged.
• DONOToperategeneratorintherainorwetweather.
• DONOThandlegeneratororelectricalcordswhilestandinginwater,while
barefoot, or while hands or feet are wet.
• DONOTallowunqualifiedpersonsorchildrentooperateorservicegenerator.
8 BRIGGSandSTRATTON.COM
WARNING Damaged or overloaded electrical cables could overheat, arc, and
burn resulting in death, serious injury, and/or property damage.
• ONLYusesuitablyratedextensioncables.
• Followallsafetyinstructionsonextensioncables.
• Inspectcablesbeforeeachuse.
WARNING Starter cord kickback (rapid retraction) will pull hand and arm
toward engine faster than you can let go which could cause broken
bones, fractures, bruises, or sprains resulting in serious injury.
• Whenstartingengine,pullcordslowlyuntilresistanceisfeltandthenpullrapidly
to avoid kickback.
• NEVERstartorstopenginewithelectricaldevicespluggedinandturnedon.
WARNING Running engine gives off carbon monoxide, an odorless,
colorless, poison gas.
Breathing carbon monoxide could result in death, serious injury, headache,
fatigue, dizziness, vomiting, confusion, seizures, nausea or fainting.
• OperatethisproductONLYoutdoors.
• Installabatteryoperatedcarbonmonoxidealarmnearthebedrooms.
• Keepexhaustgasfromenteringaconfinedareathroughwindows,doors,
ventilation intakes, or other openings.
• DONOToperatethisproductinsideanybuilding,carport,porch,mobile
equipment, marine applications, or enclosure, even if windows and doors are open.
