13
Inspect Muffler and Spark Arrester Figure
10
Inspect the muffler for cracks, corrosion, or other damage. Remove the spark arrester,
if equipped, and inspect for damage or carbon blockage. If replacement parts are
required, make sure to use only original equipment replacement parts.
Clean and inspect the spark arrester as follows:
1. To remove muffler guard (A), remove screws that connects guard to muffler (B).
2. Remove screws that attaches spark arrester screen (C) to muffler. Remove
spark arrester screen.
3. Inspect screen and obtain a replacement if torn, perforated or otherwise
damaged. DO NOT use a defective screen. If screen is not damaged, clean it
with a brush.
4. Reattach screen to muffler. Reattach muffler guard.
Clean Cooling System
Figure
11
Over time debris may accumulate in cylinder cooling fins and cannot be observed
without partial engine disassembly. For this reason, we recommend you have a Briggs
& Stratton authorized dealer clean the cooling system (A) per recommended intervals
(see Maintenance Schedule in the Maintenance section). Equally important is to keep
top of engine free from debris. Also see Cleaning.
Carburetor Adjustment
The carburetor on this engine is low emission. It is equipped with a non-adjustable idle
mixture valve. Top speed has been set at the factory. If adjustment is required, see a
Briggs & Stratton authorized dealer.
Storage
*GZPVXJMMOPUCFVTJOHUIFHFOFSBUPSGPSNPSFUIBOøEBZTVTFUIFGPMMPXJOH
guidelines to prepare it for storage.
Generator Storage
t$MFBOUIFHFOFSBUPSBTPVUMJOFEJOCleaning.
t$IFDLUIBUDPPMJOHBJSTMPUTBOEPQFOJOHTPOHFOFSBUPSBSFPQFOBOEVOPCTUSVDUFE
Long Term Storage Instructions
Fuel can become stale when stored over 30 days. Stale fuel causes acid and gum
deposits to form in the fuel system or on essential carburetor parts. To keep fuel fresh,
use Briggs & Stratton FRESH START® fuel stabilizer, available as a liquid additive or a
drip concentrate cartridge.
There is no need to drain petrol from the engine if a fuel stabilizer is added according
to instructions. Run the engine for 2 minutes to circulate the stabilizer throughout the
GVFMTZTUFN5IFFOHJOFBOEGVFMDBOUIFOCFTUPSFEVQUPøNPOUIT
If petrol in the engine has not been treated with a fuel stabilizer, it must be drained into
an approved container. Run the engine until it stops from lack of fuel. The use of a fuel
stabilizer in the storage container is recommended to maintain freshness.
Change Engine Oil
While engine is still warm, drain oil from crankcase. Refill with recommended grade.
See Changing Engine Oil.
Other Storage Tips
1. DO NOT store fuel from one season to another unless it has been treated as
described in Long Term Storage Instructions.
2. Replace fuel container if it starts to rust. Rust and /or dirt in fuel can cause
problems if it’s used with this unit.
3. Cover unit with a suitable protective cover that does not retain moisture.
4. Store generator in clean, dry area.
WARNING Contact with muffler area can result in serious burns.
Exhaust heat /gases can ignite combustibles, structures or
damage fuel tank causing a fire.
t%0/05UPVDIIPUQBSUTBOE"70*%IPUFYIBVTUHBTFT
t"MMPXFRVJQNFOUUPDPPMCFGPSFUPVDIJOH
t,FFQBUMFBTUNøGFFUPGDMFBSBODFPOBMMTJEFTPGHFOFSBUPSJODMVEJOH
overhead.
t$POUBDUUIFPSJHJOBMFRVJQNFOUNBOVGBDUVSFSSFUBJMFSPSEFBMFSUPPCUBJOBTQBSL
arrester designed for the exhaust system installed on this engine.
t3FQMBDFNFOUQBSUTNVTUCFUIFTBNFBOEJOTUBMMFEJOUIFTBNFQPTJUJPOBTUIF
original parts.
WARNING Fuel and its vapors are extremely flammable and explosive which
could cause burns, fire or explosion resulting in death, serious
injury and/or property damage.
WHEN STORING FUEL OR EQUIPMENT WITH FUEL IN TANK
t4UPSFBXBZGSPNGVSOBDFTTUPWFTXBUFSIFBUFSTDMPUIFTESZFSTPSPUIFS
appliances that have pilot light or other ignition source because they could ignite
fuel vapors.
WHEN DRAINING FUEL
t5VSOHFOFSBUPSFOHJOF0''BOEMFUJUDPPMBUMFBTUNJOVUFTCFGPSFSFNPWJOHGVFM
cap. Loosen cap slowly to relieve pressure in tank.
t%SBJOGVFMUBOLPVUEPPST
t,FFQGVFMBXBZGSPNTQBSLTPQFOGMBNFTQJMPUMJHIUTIFBUBOEPUIFSJHOJUJPO
sources.
t$IFDLGVFMMJOFTUBOLDBQBOEGJUUJOHTGSFRVFOUMZGPSDSBDLTPSMFBLT3FQMBDFJG
necessary.
t%0/05MJHIUBDJHBSFUUFPSTNPLF
WARNING Storage covers could cause a fire resulting in death, serious
injury and/or property damage.
t%0/05QMBDFBTUPSBHFDPWFSPWFSBIPUHFOFSBUPS
t-FUFRVJQNFOUDPPMGPSBTVGGJDJFOUUJNFCFGPSFQMBDJOHUIFDPWFSPOUIFFRVJQNFOU
CAUTION Excessively high operating speeds could result in minor injury
and/or generator damage.
Excessively low speeds impose a heavy load.
t%0/05UBNQFSXJUIHPWFSOPSTQSJOHMJOLTPSPUIFSQBSUTUPJODSFBTFFOHJOFTQFFE
t%0/05NPEJGZHFOFSBUPSJOBOZXBZ
