7
Assembly
Your generator is ready for use after it has been properly serviced with the
recommended fuel and oil.
If you have any problems with the servicing of your generator, contact your local Briggs
& Stratton service center. If you need assistance, please have the model, revision, and
serial number from the identification label available. See Features and Controls for
identification label location.
Unpack Generator
1. Set the carton on a rigid, flat surface.
2. Remove everything from carton.
The generator is supplied with:
t0QFSBUPSTNBOVBM
t#BUUFSZGMPBUDIBSHFS
t,FZT
Add Engine Oil
1. Place generator on a level surface.
2. Add engine oil as described in Adding Engine Oil of the Engine
Maintenance section.
NOTICE
Improper treatment of generator could damage it and shorten its life.
t%0/05BUUFNQUUPDSBOLPSTUBSUUIFFOHJOFCFGPSFJUIBTCFFOQSPQFSMZ
serviced with the recommended oil. This could result in an engine failure.
Add Fuel Figure
1
Fuel must meet these requirements:
t$MFBOGSFTIVOMFBEFEQFUSPM
t"NJOJNVNPGPDUBOF",*30/'PSIJHIBMUJUVEFVTFTFFHigh Altitude.
t1FUSPMXJUIVQUPFUIBOPMHBTPIPMPSVQUP.5#&NFUIZMUFSUJBSZ
butyl ether) is acceptable.
NOTICE Avoid generator damage.
Failure to follow Operator’s Manual for fuel recommendations voids warranty.
t%0/05VTFVOBQQSPWFEQFUSPMTVDIBT&
t%0/05NJYPJMJOQFUSPM
t%0/05NPEJGZFOHJOFUPSVOPOBMUFSOBUFGVFMT
To protect the fuel system from gum formation, mix in a fuel stabilizer when adding
fuel. See Storage. All fuel is not the same. If you experience starting or performance
problems after using fuel, switch to a different fuel provider or change brands. This
engine is certified to operate on petrol. The emission control system for this engine is
EM (Engine Modifications).
1. Clean area around fuel fill cap, remove cap.
2. Slowly add unleaded fuel (A) to fuel tank (B). Be careful not to fill above the
baffle (C). This allows adequate space for fuel expansion as shown.
3. Install fuel cap and let any spilled fuel evaporate before starting engine.
High Altitude
"UBMUJUVEFTPWFSNFUFSTGFFUBNJOJNVNøPDUBOF",*
RON) petrol is acceptable. To remain emissions compliant, high altitude adjustment
is required. Operation without this adjustment will cause decreased performance,
increased fuel consumption, and increased emissions. See a Briggs & Stratton
Authorized Dealer for high altitude adjustment information. Operation of the engine at
altitudes below 750 meters (2,500 feet) with the high altitude kit is not recommended.
Attach Negative Battery Cable Figure
2
Your unit is equipped with electric start capability but can be started manually. If you
choose not to use the electric start feature, you do not need to connect the negative
battery cable.
The sealed battery on the generator is pre–installed except for the negative (black)
battery cable.
To install:
1. Cut off tie wrap securing loose end of negative (black) cable.
2. Using an 8 mm socket wrench, remove screw (A), lock washer (B) and flat
washer (C) on negative battery terminal.
3. Slide lock washer, flat washer and negative battery cable (D) over screw as shown.
4. Reattach screw to negative battery terminal and tighten.
5. Verify that connections to battery and generator are tight and secure.
NOTICE If your battery is discharged, charge prior to use following the instructions in
the section Battery Charger.
Features and Controls Figure
3
Read this Operator’s Manual and safety rules before operating your
generator. Compare the illustrations with your generator, to familiarize
yourself with the locations of various controls and adjustments. Save this
manual for future reference.
A - Start Switch — Turn key to start (
) position to start the engine. Turn key to off
(O) position to switch off engine.
B - Hour Meter — Displays and records how many hours your generator has run (up
to 9,999.9).
C - Choke Control — Used when starting a cold engine.
D - Battery Float Charger Jack — Use battery float charger jack to keep the starting
battery charged and ready for use.
E - 230 Volt AC Outlets — May be used to supply electrical power for the operation of
ø7PMU"$TJOHMFQIBTFø)[FMFDUSJDBMMJHIUJOHBQQMJBODFUPPMBOENPUPSMPBET
F - Circuit Breakers (AC) — The receptacles are provided with circuit breakers to
protect the generator against electrical overload.
G - Oil Fill Cap/Dipstick — Check and add engine oil here.
H - Oil Drain Plug — Drain engine oil here.
J - Spark Arrester Muffler — Exhaust muffler lowers engine noise and is equipped
with a spark arrester screen.
K - Grounding Fastener — Consult your local agency having jurisdiction for grounding
requirements in your area.
L - Identification Label — Provides model and serial number of generator. Please
have these readily available if calling for assistance.
M - Air Cleaner — Protects engine by filtering dust and debris out of intake air.
N - Recoil Starter — Used to start the engine manually.
P - Fuel Valve — Used to turn fuel supply on and off to engine.
R - Fuel Tank — Capacity of 30 liters (eight (8) U.S. gallons).
Items Not Shown:
Engine Identification — Provides model, type and code of engine. Please have these
readily available if calling for assistance.
Battery Charger Figure
3
Use battery float charger jack to keep the starting battery charged and ready for use.
Battery charging should be done in a dry location, such as inside a garage.
1. Plug charger into unit’s battery float charger jack (3, D), which is located below
the start switch. Plug battery charger into a 230 Volt AC wall receptacle.
2. Unplug charger from unit and wall outlet when generator is being started and
while it is in operation.
3. Keep this charger plugged in when generator is not in use to prolong battery
life. The charger has a built in float equalizer and will not overcharge the
battery, even when plugged in for an extended period of time.
NOTICE See Battery Maintenance for additional information.
WARNING Fuel and its vapors are extremely flammable and explosive which
could cause burns, fire or explosion resulting in death, serious
injury and/or property damage.
WHEN ADDING FUEL
t5VSOHFOFSBUPSFOHJOF0''BOEMFUJUDPPMBUMFBTUNJOVUFTCFGPSFSFNPWJOHGVFM
cap. Loosen cap slowly to relieve pressure in tank.
t'JMMGVFMUBOLPVUEPPST
t%0/05PWFSGJMMUBOL"MMPXTQBDFGPSGVFMFYQBOTJPO
t*GGVFMTQJMMTXBJUVOUJMJUFWBQPSBUFTCFGPSFTUBSUJOHFOHJOF
t,FFQGVFMBXBZGSPNTQBSLTPQFOGMBNFTQJMPUMJHIUTIFBUBOEPUIFSJHOJUJPOTPVSDFT
t$IFDLGVFMMJOFTUBOLDBQBOEGJUUJOHTGSFRVFOUMZGPSDSBDLTPSMFBLT3FQMBDFJG
necessary.
t%0/05MJHIUBDJHBSFUUFPSTNPLF
