Issues Solutions❑and❑Explanations

You have intermittent

loss of audio or video.

●

Check the cable connections and reconnect them.

●

Loss of audio or video can be caused by using overly

rigid or thick cables. Make sure the cables are ﬂexible

enough for long term use. If mounting the TV to the wall,

we recommend using cables with 90 degree connectors.

You see small particles

when you look closely

at the edge of the

frame of the TV.

●

This is part of the product’s design and is not a defect.

The PIP menu is not

available.

●

PIP functionality is only available when you are using a

HDMI, PC or components source.

English
