Samsung UE27D5020NW [60/191] You can attach your tv to your lan by connecting the lan port on the back

◀ ▶

◀

●

You can attach your TV to your LAN by connecting the LAN port on the back

of your TV to a IP Sharer which is connected to an external modem. Use LAN

cable for the connection. See the diagram below.

The Modem Port on the Wall

External Modem

(ADSL / VDSL / Cable TV)

IP Sharer

(having DHCP server)

TV Rear Panel

LAN Cable

Modem Cable

English
