Samsung UE27D5020NW [68/191] Connecting to a wireless network

◀ ▶

◀

❑

Connecting❑to❑a❑Wireless❑Network❑

for LED 5 series 32-46 inches

To connect your TV to your network wireless, you need a wireless router or modem

and a Samsung Wireless LAN Adapter (WIS09ABGN, WIS09ABGN2, WIS10ABGN),

which you connect to your TV’s back or side panel USB port. See the illustration

below.

LAN Cable

Wireless IP sharer

(Wireless router having DHCP

Server)

Samsung Wireless

LAN Adapter

TV Side Panel

The LAN Port on the Wall

English
