Samsung UE27D5020NW [73/191] Notice

▶

◀ ▶

Notice

The picture may appear corrupted or have static for some channels when the TV

is connected to the Samsung Wireless LAN Adapter. In such a case, establish a

connection using one of the following methods or connect the Samsung Wireless LAN

Adapter using a USB cable in a place that is not affected by radio interference.

Method 1

Connect using the USB right angle adapter To connect the Samsung Wireless LAN

Adapter using the USB right angle adapter, follow these steps:

1. Connect the USB right angle adapter to the

Samsung Wireless LAN Adapter.

2. Connect the other end of the right angle

adapter to the USB port.

English
