Samsung UE27D5020NW [57/191] Selecting the sound mode

▶

◀ ▶

❑❑ Selecting❑the❑Sound❑Mode

❑

DUAL❑I-II❑

→

❑ENTER

When you set to Dual I-II, the current sound mode is displayed on the screen.

Audio Type Dual I-II Default

A2 Stereo

Mono Mono

Automatic change

Stereo

Stereo❑↔❑Mono

Dual

Dual I❑↔❑Dual II

Dual I

NICAM Stereo

Mono Mono

Automatic change

Stereo

Mono❑↔❑Stereo

Dual

Mono❑→❑Dual I

❑Dual II❑

Dual I

If the stereo signal is weak and an automatic switching, occurs, then switch to

the mono.

Only activated in stereo sound signal.

Only available when the Source is set to TV.
