Samsung UE27D5020NW [32/191] Screen adjustment

◀ ▶

◀

❑

■

Screen❑Adjustment

Set the various picture options such as picture size and aspect ratio.

●

Picture❑Size: Your cable box/satellite receiver may have its own set of screen

sizes as well. However, we highly recommend you use 16:9 mode most of the

time.

Auto❑Wide: Automatically adjusts the picture size to the 16:9 aspect ratio.

16:9: Sets the picture to 16:9 wide mode.

Wide❑Zoom: Magniﬁes the picture size more than 4:3.

Adjusts the Position by using

▲

▼

buttons.

Zoom: Magniﬁes the 16:9 wide pictures vertically to ﬁt the screen size.

Adjusts the Zoom or Position by using

▲

▼

button.

English
