Samsung UE27D5020NW [81/191] Network setup one foot connection

▶

◀ ▶

❑

■

Network❑Setup❑(One❑Foot❑Connection)

The One❑Foot❑Connection make you easy to connect samsung TV and samsung

wireless router by placing samsung wireless router within 1foot(25cm) from

samsung TV. If your wireless router does not support One❑Foot❑Connection, you

must connect using one of the other methods.

You can check for equipment that supports One❑Foot❑Connection on www.

samsung.com.

How❑to❑set❑up❑using❑One❑Foot❑Connection❑

Turn on the power of wireless router and TV.

1. Go to Network❑Settings screen. To enter it, follow the directions of Network❑

Settings.

English
