Hikoki CR13VEYNSZ [3/152] Additional safety warnings
![Hikoki CR13VEYNSZ [3/152] Additional safety warnings](/views2/1885512/page3/bg3.png)
3
English
5) Service
a) Have your power tool serviced by a qualifi ed
repair person using only identical replacement
parts.
This will ensure that the safety of the power tool is
maintained.
PRECAUTION
Keep children and infi rm persons away.
When not in use, tools should be stored out of reach of
children and infi rm persons.
RECIPROCATING SAW SAFETY
WARNINGS
1. Hold the power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring or its own
cord.
Cutting accessory contacting a "live" wire may make
exposed metal parts of the power tool "live" and could
give the operator an electric shock.
2. Use clamps or another practical way to secure and
support the workpiece to a stable platform.
Holding the workpiece by hand or against your body
leaves it unstable and may lead to loss of control.
ADDITIONAL SAFETY WARNINGS
1. Preparing and checking the work environment. Make
sure that the work site meets all the conditions laid forth
in the precautions.
2. Ensure that the power source to be utilized conforms
to the power requirements specifi ed on the product
nameplate.
3. Ensure that the power switch is in the OFF position.
If the plug is connected to a receptacle while the power
switch is in the ON position, the power tool will start
operating immediately, which could cause a serious
accident.
4. When the work area is removed from the power source,
use an extension cord of suffi cient thickness and rated
capacity. The extension cord should be kept as short as
practicable.
5. Prior to cutting into walls, ceilings or fl oors, ensure there
are no electric cables or conduits inside.
6. Dust produced in operation
The dust produced in normal operation may aff ect the
operator’s health. To wear a dust mask is recommended.
7. When using this unit continuously, the unit may overheat,
leading to damage in the motor and switch. Therefore,
whenever the housing becomes hot, give the saw a
break for a while.
8. If the machine is used continuously at minimum speed,
an extra load is applied to the motor which can result in
motor seizure. Always operate the power tool so that
the blade is not caught by the material during operation.
Always adjust the blade speed to enable smooth cutting.
9. Always hold the body handle and front cover of the
power tool fi rmly. Otherwise the counterforce produced
may result in inaccurate and even dangerous operation.
10. Mounting the blade (Fig. 5)
This unit employs a detachable mechanism that enables
mounting and removal of saw blades without the use of a
wrench or other tools.
○ Turn off the switch and unplug the power cord.
Be absolutely sure to keep the switch turned off and the
power cord unplugged to prevent any accident.
○ Pull the back of the saw blade two or three times by hand
and check that the blade is securely mounted. When
pulling the blade, you will know it is properly mounted if it
clicks and the lever moves slightly.
○ When pulling the saw blade, be absolutely sure to pull it
from the back. Pulling other parts of the blade will result
in an injury.
11. Maintenance and inspection of saw blade mount
○ After use, blow away sawdust, earth, sand, moisture,
etc., with air or brush them away with a brush, etc., to
ensure that the blade mount can function smoothly.
○ As shown in Fig. 14, carry out lubrication around the
blade holder on a periodic basis by use of cutting fl uid,
etc.
○ Continued use of the tool without cleaning and lubricating
the area where the saw blade is installed can result in
some slack movement of the lever due to accumulated
sawdust and chips. Then, clean up the inside of the
blade holder with air and the like and carry out suffi cient
lubrication.
○ Do not use any saw blade with a worn-out blade hole
(A). Otherwise, the saw blade can come off , resulting in
personal injury. (Fig. 1)
12. Adjusting the swing cutting operation
○ Even for soft materials, you should perform straight
cutting if you wish to make curved or clean cuts.
○ Dust and dirt accumulated on the change lever
section can degrade the function of the change lever.
Periodically clean the change lever section.
○ When performing swing cutting, use a saw with straight
blade. If a saw with curved blade is used, the saw blade
may be broken or the unit may be damaged.
13. How to use
○ Avoid carrying it plugged to the outlet with your fi nger on
the switch. A sudden startup can result in an unexpected
injury.
○ Be careful not to let sawdust, earth, moisture, etc., enter
the inside of the machine through the plunger section
during operation. If sawdust and the like accumulate in
the plunger section, always clean it before use.
○ Do not remove the front cover. Hold fi rmly the front cover
by hand to operate. But, do not extend your hand or
fi nger beyond the fl ange of front cover to avoid an injury.
○
During use, press the base against the material while
cutting.
Vibration can damage the saw blade if the base is not
pressed fi rmly against the workpiece.
Furthermore, a tip of the saw blade can sometimes
contact the inner wall of the pipe, damaging the saw blade.
○ Select a saw blade of the most appropriate length.
Ideally, the length protruding from the base of the saw
blade after subtracting the stroke quantity should be
larger than the material (see Fig. 10).
If you cut a large pipe, large block of wood, etc., that
exceeds the cutting capacity of a blade; there is a risk
that the blade may contact with the inner wall of the pipe,
wood, etc., resulting in damage.
○ To maximize cutting effi ciency for the materials you are
using and working conditions, adjust the speed of the
saw blade and the switching to swing cutting.
Cutting
○ Press the base fi rmly against the workpiece.
○ Never apply any unreasonable force to the saw blade
when cutting. Doing so can easily break the blade.
○ Fasten a workpiece fi rmly before operation. (Fig. 11)
○ When cutting metallic materials, use proper machine
oil (turbine oil, etc.). When not using liquid machine oil,
apply grease over the workpiece.
The service life of the saw blade will be drastically
shortened if you don’t use machine oil.
○ Never apply any unreasonable force to the saw blade
when cutting. Also remember to press the base against
the lumber fi rmly.
Sawing curved lines
○ We recommend that you use the BI-METAL blade
mentioned in Table 2 for the saw blade since it is tough
and hardly breaks.
0000BookCR13VEY.indb30000BookCR13VEY.indb3 2018/12/2712:10:432018/12/2712:10:43
