Hikoki CR13VEYNSZ [5/152] Applications
![Hikoki CR13VEYNSZ [5/152] Applications](/views2/1885512/page5/bg5.png)
5
English
Orbital cutting
Stroke
Disconnect mains plug from electrical outlet
Class II tool
Warning
Prohibited action
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package
contains the accessories listed on page 143.
Standard accessories are subject to change without notice.
APPLICATIONS
○ Cutting metal and stainless steel pipe.
○ Cutting various lumbers.
○ Cutting mild steel plates, aluminum plates, and copper
plates.
○ Cutting synthetic resins, such as phenol resin and vinyl
chloride.
For details refer to the section entitled “SELECTION OF
BLADES”.
SPECIFICATIONS
Voltage (by areas) *
(110 V, 220 V, 230 V,
240 V)
Power Input * 1100 W
Capacity
Mild Steel Pipe O.D. 130 mm
Vinyl Chloride
Pipe
O.D. 130 mm
Wood Depth 300 mm
Mild Steel Plate Thickness 19 mm
No-Load Speed 0 – 3000 min
–1
Stroke 32 mm
Weight (without cord) ** 3.9 kg
* Be sure to check the nameplate on product as it is
subject to change by areas.
** According to EPTA-Procedure 01/2014
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
MOUNTING AND OPERATION
Action Figure Page
Switch Operation
2
138
Adjusting operating speed*
1
3
139
Adjusting stroke
4
139
Mounting the blade 5 139
Dismounting the blade*
2
6 140
When the blade broken*
3
7 140
Adjusting the base 8 140
How to use the hook*
4
9 140
Select a saw blade of the
appropriate length
10
141
Fastening work piece fi rmly
11
141
Plunge cutting (for wood) 12 141
Plunge cutting with the saw blade
installed in reverse
13 142
Maintenance and inspection of
saw blade mount
14 142
Selecting accessories ― 144
Refer to Table 1, 2 and 3 for use of the blades.
*1 Adjusting operating speed
CAUTION
Select mode while the trigger switch is released. Failure
to do so could result in malfunction.
Once you connect the power plug to an outlet and switch on
the power, you can change modes with each press of the
mode selector switch.
● Speed change mode allows the number of maximum
strokes to be switched between 5 levels: minimum
speed, low speed, middle speed, high speed and Max.
speed.
With speed change mode, the set number of maximum
strokes will be maintained even if there is a change in
load.
Operating speed
Mode Status Operating speed
Transmisson
Mode
Min. 0 – 1200 min
-1
Low 0 – 1700 min
-1
Middle 0 – 2000 min
-1
High 0 – 2500 min
-1
Max. 0 – 3000 min
-1
*2 Dismounting the blade
CAUTION
Never touch the saw blade immediately after use. The
metal is hot and can easily burn your skin.
(1) After pivoting the lever, point the blade downward. The
blade should fall out on its own. If the blade fails to fall
out, pull it out by hand. (Fig. 6)
*3 When the blade is broken
Even when the saw blade is broken and remains inside
the small slit of the blade holder, it should fall out when
the lever is pivoted and the blade is pointed downward.
If the blade fails to fall out on its own, take it out by using
the procedures described below.
(1) If a part of the broken saw blade is sticking out of the
small slit of the blade holder, pull out the protruding part
and take the blade out.
0000BookCR13VEY.indb50000BookCR13VEY.indb5 2018/12/2712:10:442018/12/2712:10:44
