Input Terminals
8
A
Input
terminal for AC/DC
current
measurements
to 9.999A.
μA/mA
Input
terminal for AC/DC
current
measurements
to 99.99mA.
COM
Common
(return) terminal for
all
measurements
.
Input
terminal for the measurements of:
1
. Diode
2
. Continuity
3
. Square wave
4
. Temperature
5
. AC/DC voltage
6
. Resistance
7
. Frequency
8
. Capacitance
