Zotek ZTY [21/26] Specifications
![Zotek ZTY [21/26] Specifications](/views2/1893221/page21/bg15.png)
Specifications
17
General Specifications
Display
（LCD）
9999 Counts
Ranging
Auto/Manual
Material
ABS+TPE
Update Rate
3 Times/Second
Ture RMS
√
Data Hold
√
Backlight
√
Low Battery Indication
√
Auto Power Off
√
Mechanical Specifications
Dimension
147*76*37mm
Weight
191g（without batteries）
Battery Type
1.5V AAA Battery * 3
Warranty
One year
Environmental Specifications
Operating
Temperature 0~40℃
Humidity
＜75%
Storage
Temperature -20~60℃
Humidity
＜80%
