Zotek ZTX [11/26] Push this button when the product is at the
![Zotek ZTX [11/26] Push this button when the product is at the](/views2/1893222/page11/bgb.png)
⑦
Push
this button when the product is at
the
setting
of ACV, the primary
measurement
display
will show the current
frequency
(1
~100kHz) while the secondary
measurement
display
will show the current duty cycle.
Push
this button when the product is at
the
setting
of ACmV, the primary
measurement
display
will show the current
frequency
(1
~5MHz) while the secondary
measurement
display
will show the current duty cycle.
7
